Main Technical Specifications | ||||||||||||||
Model | CNF170FB(E) | CNF173F | CNF178F(E) | CNF186FA(E) | CNF188FA(E) | CNF192F(E) | CNF1100FE | |||||||
Type | Single cylinder,Vertical,4-stroke,air-cooled,Direct injection | |||||||||||||
Bore'stroke(mm) | 70x54 | 73x60 | 78x62 | 86x72 | 88x75 | 92x75 | 100x75 | |||||||
Displacement(L) | 0.227 | 0.251 | 0.296 | 0.406 | 0.456 | 0.498 | 0.59 | |||||||
Rated output power(KW) | 3.3/3000 3.6/3600 | 3.3/3000 3.7/3600 | 3.7/3000 4.0/3600 | 5.7/3000 6.5/3600 | 6.6/3000 7.2/3600 | 7.5/3000 8.2/3600 | 9.3/3000 10.0/3600 | |||||||
Rated speed(ri/min) | 3000/3600 | |||||||||||||
Starting system | Recoil or electric start | |||||||||||||
Power take of | Crankshaft or camshaft(camshaft PTO rpm is 1/2) | |||||||||||||
Fuel tank capacity(L) | 2.5 | 2.5 | 3.5 | 5.5 | 5.5 | 5.5 | 5.5 | |||||||
Lube oi capacity(L) | 0.75 | 0.75 | 1.1 | 1.65 | 1.65 | 1.65 | 1.65 | |||||||
Dimeensions L'W'H(mm) | 332x392x416 | 335x380x415 | 383x421x450 | 420x470x495 | 420x470x495 | 420x470x495 | 420x470x495 | |||||||
Dry weight(recoil)(kg) | 27 | 30.5 | 33 | 49 | 49 | 50 | 55 | |||||||
Dry weight(recoil)(kg) | 32 | 32 | 38 | 51 | 53 | 54 | ||||||||
