P2.6 P2.9 P3.91 Church Public Indoor LED Video Wall Screen P4.81 P5.9 Portable Rental Stage Backdrops Outdoor LED Panel Display
- Category: >>>
- Supplier: Madder Engineering & Technology Co. Ltd.
Share on (1601111837729):
Product Overview
Description
Product Description
Specification
Working environment | INDOOR | ||||||||||||
Model Number | MI1.56 | MI1.95 | MI2.5 | MI2.6 | MI2.97 | MI3.91 | MI4.81 | ||||||
Pixel Pitch (mm) | 1.56 | 1.95 | 2.5 | 2.6 | 2.97 | 3.91 | 4.81 | ||||||
Physical Density (pixels/m²) | 409,600 | 262,144 | 160,000 | 147,456 | 112,896 | 65,536 | 43,264 | ||||||
LED Arrangement | 3IN 1 SMD | 3IN 1 SMD | 3IN1 SMD | 3IN1SMD | 3IN1 SMD | 3 IN1SMD | 3IN1 SMD | ||||||
Module Dimensions | 250mm × 250mm | 250×250 | 250×250 | 250×250 | 250×250 | 250×250 | 250×250 | ||||||
Module Resolution | 160×160 | 128×128 | 100×100 | 96x96 | 84x84 | 64×64 | 52x52 | ||||||
Cabinet Dimensions | 500mm × 500mm × 85mm / 500mm × 1000mm x 85mm | 500×500×85 / 500×1000x85 | 500×500×85 / 500×1000x85 | 500×500×85 / 500×1000x85 | 500×500×85 / 500×1000x85 | 500×500×85 / 500×1000x85 | 500×500×85 / 500×1000x85 | ||||||
Cabinet Weight | 8kg / 14kg | 8kg/14kg | 8kg/14kg | 8kg/14kg | 8kg/14kg | 8kg/14kg | 8kg/14kg | ||||||
Brightness (nits) | 800 | 800 | 1,000 | 1,000 | 1,000 | 1,000 | 1,000 | ||||||
Max Power Consumption | 300W/m² | 300w/pane | 300w/pane | 300w/pane | 300w/pane | 300w/pane | 300w/pane | ||||||
Avg.Power Consumption | 140W/m² | 140w/panel | 140w/panel | 140w/panel | 140w/panel | 140w/panel | 140w/panel | ||||||
Viewing Angle | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160 | ||||||
Operating Power Source | AC200-240V 50-60Hz | AC200-240V 50-60Hz | AC200-240V50-60Hz | AC200-240V 50-60Hz | AC200-240V 50-60Hz | AC200-240V 50-60Hz | AC200-240V 50-60Hz | ||||||
Operating Temperature | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | -10℃~+45℃ | ||||||
Refresh Rate | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | ||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Company Profile
Shenzhen Mingqi Zhida Engineering Technology Co., Ltd. is a comprehensive engineering and technology enterprise focusing on LED display, integrating equipment management system, security monitoring and engineering installation.
