ZM 2016wh Free Installation On Grid All In One Home Smart Balcony Solar Energy 800w Storage System with DY APstm Inverter
- Category: >>>
- Supplier: Zhimai (shenzhen) New Energy Co. Ltd.
Share on (1601113486965):
Product Overview
Description
Product Description
Specification
Features | Descriptions | |
Battery Pack Parameter | ||
Battery Type | LFP | |
Cycle | 6000 cycles to 80% | |
Capacity | 2016wh(44.8V 45AH) | |
Charging protection temperature | 50℃ | |
Discharge protection temperature | 60℃ | |
Sleeping current | 100mΩ | |
Battery voltage platform | 3.2V | |
Single cell capacity | 15AH | |
Pack type | 14 in series/3 in parallel | |
Expansion | 2 max expansion packages | |
PV Charging Input Parameter | ||
Port type | 2 sets of MC4 Female connector: positive Male connector: negative | |
Input voltage range | Min 12V to Max 60V | |
Input over-voltage protection | 70V | |
Charging current | Max 23A | |
Charging power | 1500W: 750W*2 | |
Conversion efficiency | 96%(Tested by 60V input) | |
Output Parameter | ||
Port type | 2 sets of MC4 Female connector: positive Male connector: negative | |
Output Voltage Range | Min 25V to Max 51.1V | |
Rated Output Current | 16A | |
Rated Output Efficiency | ≥96% (Tested by 60V input) | |
Output Power | 800W；400W*2 | |
