Thin Powerwall Batterie Lithium 48v 51.2v 200ah 100ah 10kwh 15kwh Lifepo4 Wall mounted Lithium Battery
- Category: >>>
- Supplier: Yichun Hertz Energy Storage Co. Ltd.Yichun Ltd.
Share on (1601113850454):
Product Overview
Description
Product Description
Specification
Home Lifepo4 Battery Power Wall 5kw 10KW 15KW 20KW Li Battery Pack Power Wall 24V 48V 200AH Lithium Battery | ||||||||
Model | 48V100AH | 48V150AH | 48V200AH | 48V300AH | ||||
Energy | 4800WH | 7200WH | 9600WH | 14400WH | ||||
Months Self Discharge | <3% | |||||||
Efficiency of charge | 100% @ 0.2C | |||||||
Efficiency of Discharge | 96-99%@1C | |||||||
Continuous Discharge Current (Customzied) | 50-200A (Customzied) | |||||||
Suggest charge current (Customzied) | 20A | 30A | 40A | 60A | ||||
Max Charge Current (Customzied) | 50-200A (Customzied) | |||||||
Charge Cut-Off Voltage | 55.5V±0.2V | |||||||
Discharge Cut-Off Voltage | 37.5V | |||||||
Cycle Life | ≥6000 cycles@1C 90% DOD | |||||||
Cells | Grade A | |||||||
Case | Metal Case | |||||||
Dimensions | 610*520*135 mm | 610*520*240 mm | 610*520*240mm | 821*647*168mm | ||||
Weight | 50KG | 78KG | 88KG | 128.5KG | ||||
Terminal | 100-200A (customized) | |||||||
Port | RS485/RS232/CAN | |||||||
FAQ
Q1. Can I have a sample order?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available.
Q3. How do you ship the goods since they are high capacity battery?
A: We have long-term cooperated forwarders who are professional at battery shipment.
Q4. How to proceed an order for lithium ion battery?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Q5. Do you offer guarantee for the products?
A: Yes, our products have a 12 months warranty period. If there is any quality problem in the process of using the product, please
feel free to contact us.
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. Do you have any MOQ limit?
A: Low MOQ, 1pc for sample checking is available.
Q3. How do you ship the goods since they are high capacity battery?
A: We have long-term cooperated forwarders who are professional at battery shipment.
Q4. How to proceed an order for lithium ion battery?
A: Firstly let us know your requirements or application.
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Q5. Do you offer guarantee for the products?
A: Yes, our products have a 12 months warranty period. If there is any quality problem in the process of using the product, please
feel free to contact us.
