Product Overview
Description
Standard Glass Thickness for Insulated Glass.
Considering the wind pressure and to avoid glass shaking after the installation of insulating glass.The following standards are strongly recommended for the thickness of glass before insulating.
Area（m²） | 2.0-2.6 ㎡ | 2.6-2.8 ㎡ | 2.8-3.6 ㎡ | 3.6-3.8 ㎡ | ||||
Width/Height （W/H=K) | / | K＜0.75 K＞1.3 | K≥0.75 K≤1.3 | / | K＜0.75 K＞1.3 | K≥0.75 K≤1.3 | ||
Glass Thickness | 5mm | 5mm | 6mm | 6mm | 6mm | 8mm | ||
Area（m²） | 3.8-5.6 ㎡ | 5.6-5.8 ㎡ | 5.8-7.6 ㎡ | 7.6-7.8 ㎡ | ||||
Width/Height （W/H=K) | / | K＜0.75 K＞1.3 | K≥0.75 K≤1.3 | / | K＜0.75 K＞1.3 | K≥0.75 K≤1.3 | ||
Glass Thickness | 8mm | 8mm | 10mm | 10mm | 10mm | 12mm | ||
