LH Type Electric Hoist Double Girder Bridge Overhead Cranes
$1,800.00-2,000.00
Factory free Design 5 Ton Overhead crane workshop plant electric double girder bridge crane construction lifting hoist A5 A8
- Category: >>>
- Supplier: Huahang Transportation Equipment Technology (shenzhen) Co. Ltd.
Share on (1601117765067):
Product Overview
Description
Product Description
Specification
Item | 5T double girder overhead crane bridge crane ceiling crane |
Brand | CATET |
Product Name | Single girder overhead crane |
Feature | Cost-Effective Solution, Compact design, Easy maintenance |
Span | 0-30m |
Lifting capacity | 1-10ons |
Lifting height | 0-60m |
Working level | A3-A8 |
Certification | CE, ISO9001:2015 |
Model | MATE LH |
Design standard | GB 3811-2008-T |
Color | Yellow, Red, Blue |
Condition | New |
Core component | Motor, reducer, gear box, pump, bearing |
Motor reducer | Huahang, SEW, KONE, SIMENS |
Electric component | SIMENS, Schneider, Abb |
Reduction Gear | Reducer adopts modular box, hard tooth surface gear, liquid lubricating oil, gear strength is high, wear resistance is strong, easy to replace and maintain. |
Brake | The brake adopts electromagnetic disc type power loss brake or hydraulic brake, with small size, high friction, high stability, long service life, little pollution, no asbestos dust, no risk of oil leakage. |
Wheel | made of quality steel, which is mainly used on single-beam crane. It is an important part of the traveling part of crane. Surface after heat treatment, high hardness, wear-resistant layer deep, with excellent mechanical properties and safe and reliable quality. |
drum | Wire rope drum integrated molding, with high mechanical strength and capriciousness, strong pressure resistance, high temperature quenching, anti-corrosion, long life. |
Wire Rope | The steel wire rope of hoisting mechanism is the product which conforms to the related international standard. All wire ropes are high strength wire ropes. Their responsibilities are great. The nominal tensile strength of the wire rope shall not be less than 6* 37-1770nmm2. The wire rope shall be a whole and no joints are allowed. The Factor of safety of the wire rope shall meet the requirements of the relevant regulations of the state. |
Lifting Hook | The crane hook is a forging, and the hook is designed and manufactured in compliance with DIN standards. The hook forging is made of quenched and tempered steel 34CrMoV. It is a T-grade hook that can rotate 360 degrees and has a safety buckle to prevent slipping. The surface of the hook head should be smooth and free of defects such as peeling, sharp corners, burrs, and cracks. |
Control method | Rremote control, Pendant control or customized |
Running speed | 0-20 m/min |
Lifting speed | 0-8 m/min Customized |
Place of origin | Henan Province China |
Wanrrty | 1-2 years |
Weight | 5000kg |
Steel brand | An Gang(famous in China) |
Testing report before delivery | yes |
Application | Manufacture Plant, Construction work, Factory, Energy & Mining, Steel casting |
Packing | Export standard wooden box package |
Packing & Delivery
Company Profile
Established in 1987, Bestaro Machinery(factory of Huahang), professional manufacturer of lifting equipments in China.
We can produce 1~20 tons single beam overhead crane, 5~300 tons double beam overhead crane, 1-50 tons single beam gantry crane and 5~1000 tons double beam gantry crane, 0.5~80 tons wire rope electric hoist, kinds of Hydraulic lifter, stackers, 1-500 tons transfer agv carts,AGV robots, our lifting equipments are exported to many countries.
Our company has rich experience to make high quality OEM & ODM cranes and hoists, lifters, agv carts. Brands we're serving: Chevrolet，Gree, Siemens, CRRC, CNNC, etc.
Our purpose is "Ingenious quality, rest-assured service". Welcome to visit our factory and choose our products.
We guarantee the whole set machine for 12 months, free parts would be sent during guarantee period if quality problem occurs. Also, we offer lifelong technical consulting for free ,low-maintaining cost service beyond the guarantee , on-site technical support even for overseas customers.
We can produce 1~20 tons single beam overhead crane, 5~300 tons double beam overhead crane, 1-50 tons single beam gantry crane and 5~1000 tons double beam gantry crane, 0.5~80 tons wire rope electric hoist, kinds of Hydraulic lifter, stackers, 1-500 tons transfer agv carts,AGV robots, our lifting equipments are exported to many countries.
Our company has rich experience to make high quality OEM & ODM cranes and hoists, lifters, agv carts. Brands we're serving: Chevrolet，Gree, Siemens, CRRC, CNNC, etc.
Our purpose is "Ingenious quality, rest-assured service". Welcome to visit our factory and choose our products.
We guarantee the whole set machine for 12 months, free parts would be sent during guarantee period if quality problem occurs. Also, we offer lifelong technical consulting for free ,low-maintaining cost service beyond the guarantee , on-site technical support even for overseas customers.
FAQ
1. What products can you get from us?
Overhead Crane, gantry Crane, Jib crane, track and trackless transfer cart,electric hoist, Agv robots, electric winch.etc.
2. How can we guarantee quality?
Our factory has passed the GB/T19001-2016/ISO9001: 2015 quality management system certification, all products comply with CE certificates, guaranteed for 1-3 years.
3. Why should you buy from us not from other suppliers?
Founded in 1987, Bestaro Machinery Co., Ltd. is a well-known professional manufacturer of cranes and handling equipments, choosing us means quality and service are both guaranteed.
4. What services can we provide?
a.professional sales team, inquiry will be responded within 24 hours.
b.Fast delivery-For example, the delivery time of a 50-ton crane is 6-12 working days.
c.professional research and design team,OEM and ODM are welcome.
5.How is your after-sales service?
a.guarantee the whole set machine for 12 months,
b.free parts would be sent during guarantee period if quality problem occurs.
c.lifelong technical consulting for free ,
d.low-maintaining cost service beyond guarantee.
e.long distance and on-site technical support even for overseas customers.
6.How about OEM & ODM?
Yes, we offer professional OEM & ODM service, we've cooperated with many world famous brands in different fields,such as Siemens, Gree, China Shipbuilding Industry Corporation, CRRC.etc.
Overhead Crane, gantry Crane, Jib crane, track and trackless transfer cart,electric hoist, Agv robots, electric winch.etc.
2. How can we guarantee quality?
Our factory has passed the GB/T19001-2016/ISO9001: 2015 quality management system certification, all products comply with CE certificates, guaranteed for 1-3 years.
3. Why should you buy from us not from other suppliers?
Founded in 1987, Bestaro Machinery Co., Ltd. is a well-known professional manufacturer of cranes and handling equipments, choosing us means quality and service are both guaranteed.
4. What services can we provide?
a.professional sales team, inquiry will be responded within 24 hours.
b.Fast delivery-For example, the delivery time of a 50-ton crane is 6-12 working days.
c.professional research and design team,OEM and ODM are welcome.
5.How is your after-sales service?
a.guarantee the whole set machine for 12 months,
b.free parts would be sent during guarantee period if quality problem occurs.
c.lifelong technical consulting for free ,
d.low-maintaining cost service beyond guarantee.
e.long distance and on-site technical support even for overseas customers.
6.How about OEM & ODM?
Yes, we offer professional OEM & ODM service, we've cooperated with many world famous brands in different fields,such as Siemens, Gree, China Shipbuilding Industry Corporation, CRRC.etc.
