Solar Obstacle Indicator Beacon Medium Intensity Aviation Obstruction Light GPS Synchronous for Airport Signal Lamp
- Category: >>>
- Supplier: Shaanxi Xike Intelligent Chain Technology Co. Ltd.
Share on (1601128934009):
Product Overview
Description
Product Description
1.Product Description:
TX-LS/B solar beacon light adopts advanced structural design, has 4 groups of angle adjustable low illumination, high efficiency solar panels, with solar special battery as power supply. Battery charging and discharging using advanced power management system, in the battery under-voltage, over-voltage, temperature all aspects of comprehensive protection, effectively improve the service life of the battery.
The control circuit adopts micro-power control chip, which reduces the power consumption of the control circuit itself; the light source adopts imported LED chip, which has the characteristics of high luminous brightness, low energy consumption and long service life. The product shell is made of 316L stainless steel material with baking paint, the material has the characteristics of light weight, corrosion resistance, etc., which can reduce the weight of the lamps and lanterns and help the staff to install and transport. The lampshade is made of PC material, which is characterized by corrosion resistance, UV resistance and impact resistance.
2.Application areas:
Marine waterways, rivers, lakes, mariculture areas, bridges, buoys, shore markers, fixed light piles, light towers, oil fields, derricks.
3.Main functions and features:
Designed for more than 15 days of continuous working time in cloudy and rainy days (calculated on the basis of 12 hours of working time per day).
The product has automatic light control function, in cloudy and rainy days and night lamps and lanterns automatically turn on the work.
Standardized optical design, high photoelectric conversion efficiency.
Adopting special LED chip, the conversion efficiency and life time are much higher than ordinary LED.
Impact resistance, lightning protection, sunlight resistance, rain and snow resistance, resistance to typhoons, hail and other inclement weather.
LED technology, its color meets the requirements of IALA RecommendationsE-200-1.
Replaceable sealed lead-acid batteries with a service life of more than 2 years.
With anti-bird device. No RF, no electromagnetic interference. Customizable GPS synchronization, GSM positioning and remote control switching function.
TX-LS/B solar beacon light adopts advanced structural design, has 4 groups of angle adjustable low illumination, high efficiency solar panels, with solar special battery as power supply. Battery charging and discharging using advanced power management system, in the battery under-voltage, over-voltage, temperature all aspects of comprehensive protection, effectively improve the service life of the battery.
The control circuit adopts micro-power control chip, which reduces the power consumption of the control circuit itself; the light source adopts imported LED chip, which has the characteristics of high luminous brightness, low energy consumption and long service life. The product shell is made of 316L stainless steel material with baking paint, the material has the characteristics of light weight, corrosion resistance, etc., which can reduce the weight of the lamps and lanterns and help the staff to install and transport. The lampshade is made of PC material, which is characterized by corrosion resistance, UV resistance and impact resistance.
2.Application areas:
Marine waterways, rivers, lakes, mariculture areas, bridges, buoys, shore markers, fixed light piles, light towers, oil fields, derricks.
3.Main functions and features:
Designed for more than 15 days of continuous working time in cloudy and rainy days (calculated on the basis of 12 hours of working time per day).
The product has automatic light control function, in cloudy and rainy days and night lamps and lanterns automatically turn on the work.
Standardized optical design, high photoelectric conversion efficiency.
Adopting special LED chip, the conversion efficiency and life time are much higher than ordinary LED.
Impact resistance, lightning protection, sunlight resistance, rain and snow resistance, resistance to typhoons, hail and other inclement weather.
LED technology, its color meets the requirements of IALA RecommendationsE-200-1.
Replaceable sealed lead-acid batteries with a service life of more than 2 years.
With anti-bird device. No RF, no electromagnetic interference. Customizable GPS synchronization, GSM positioning and remote control switching function.
Specification
item | value |
Warranty(Year) | 2-Year |
Color Rendering Index(Ra) | 50 |
Type | Aviation Obstruction Lights |
Support Dimmer | Yes |
Lifespan (hours) | 10000 |
Working Time (hours) | 10000 |
Product Weight（kg） | 10 |
Input Voltage(V) | AC 220V( ± 10%) |
Color Temperature(CCT) | Other |
Beam Angle(°) | 360 |
IP Rating | IP68 |
Emitting Color | red, yellow, green, blue and white |
Lamp Body Material | PC |
Light Source | LED |
Place of Origin | China |
provinces | Shaanxi |
Brand Name | xike |
Lighting solutions service | Lighting and circuitry design, Agi32 layout, Project Installation |
Solar Panel Voltage | 16.5V |
Battery Capacity | 12V14AH |
Solar Panel Power | 6wx4 pieces |
Battery Type | Specialized Battery |
Power Consumption | 2W |
Visible Distance | 5-10 nautical miles |
Light Source Lifetime | >100000 hours |
Dimension | 522 X522mmx472 |
Installation size | Sections of 200mm evenly distributed 4 m12 holes |
Working Temperature | -40℃~70℃ |
