high quality 24v 36v 48V 10Ah 20Ah 18650 lithium ion electric bike lifepo4 battery pack
- Category: >>>
- Supplier: Shandong Tian Han New Energy Technology Co. Ltd.
Share on (1601137956802):
Product Overview
Description
Remark:
The following battery is designed and developed for our customers, parameters only for showing. We can produce any customized battery according to your requirements, please advise us your actual requirements, the remaining matters leave it to us, we can definitely be trusted!
The following battery is designed and developed for our customers, parameters only for showing. We can produce any customized battery according to your requirements, please advise us your actual requirements, the remaining matters leave it to us, we can definitely be trusted!
Product Description
Specification
Nominal Voltage | 36V |
Typical Capacity | 14Ah |
Discharge | Normal Current: 14A Max Continuous Current: 20A Cut-off Voltage: about 27.5V |
Charging | Voltage: 42V Current: ≤2A Charging Cut-off current: approx 0.2A |
Inner Resistance | Discharging Inner Resistance: ≤90mΩ |
Operation Temperature/Humidity Range | Charge: 0℃ to 45℃ Discharge: -20℃ to 60℃ When the environment temperature is higher than 45℃, please pay attention to ventilation and heat rejection. Humidity Range: RH≤85%, when the environment humidity is higher than 85%, please pay attention to protect |
Storage Temperature/Humidity Range | Temperature: 0℃ to 40℃(capacity 80%) recommended long-term storage temperature is 15℃ to 25℃ Humidity: RH≤50%, easily oxidized components note sealed |
Protection Function | Over charge protection, Over discharge protection, temperature protection |
Shell Material | Aluminun 6061/PC+ABS |
Weight | 3.5±0.1kg |
Size | 435*151*66mm |
Cycle | ≥500 cycles / 80% SOC |
Packing & Delivery
Company Profile
FAQ
Q1: Are you a factory or a trading company
A1: We are a professional rechargeable lithium-ion battery and LifePO4 battery manufacturer located in Shandong. We passed ISO9001:2008 quality system certification.
Q2: Can I have samples to test? And what is lead time for sample order?
A2: Yes,we can supply samples,the lead time for samples is 7-10 days.and buyer pay for sample cost and shipping cost.
Q3: Do you provide after-sales service?
A3: Yes,the warranty is 3 years, if any quality problems on our side in this period, we can send new one as replacement.
Q4: What is your company's advantage?
A4: We only supply high level quality of
lithium battery and we guarantee on-time shipment,we also provide excellent after sales service
lithium battery and we guarantee on-time shipment,we also provide excellent after sales service
Q5: Do you accept OEM/ODM?
A5: Yes,it is available.
Q6: What information do you need to make a customized battery pack?
A6: We need the details below: 1. Size of the battery pack you need in mm. 2. Capacity of the Battery pack. 3. Voltage of the battery pack. 4. Max discharge current. 5. Cable and connector types you need. 6. Casing and Terminals if required. 7. Any protection circuits you may need.
Q7: Are you battery real capacity?
A7: All of our battery cells with Grade A,100% new and real capacity.
Q8: What kind of certificates do you have?
A8: We can provide CE,ROHS,FCC,IEC62133,MSDS,UN38.3.
Q9: What is your lead time for the mass production?
A9: General speaking, about 25-30 days depending on different items after getting down payment and confirmation about the samples.
