Hydraulic ladder lift truck telescopic boom bucket truck 45m telescopic boom aerial work platform truck hot sale

Product name

SINOTRUK Chassis ladder truck

Model

JNRY-YTC

     Technological

Double luffing cylinder, arm lifting, swinging more stable

Electronically controlled power take-off, the power take-off handbrake cannot be operated at the same time (alarm prompt)

The width of the widened ladder arm is 1020mm, and the trolley works up and down more smoothly and safely

Horizontal double-row ladder winch, wire rope diameter 10mm, ladder arm lifting more stable.

The power take-off is directly connected to the duplex pump, with a large displacement, faster action speed, higher pressure and
larger output torque of each component.

Six legs 2 front and 4 rear (2 auxiliary legs), the vehicle support is more stable, protecting the frame and chassis. The
two-stage legs are linked by wire ropes with a super large span, with a front and rear span of 5 meters and a transverse span of 6
meters.

Equipped with two toolboxes and a built-in air pump for external pneumatic tools.

The precision and stability of the electrical system are higher, and the operating handle adopts a linear pusher, which has
stepless speed change and stronger controllability. Hopper control and ladder control are 2-in-1 and integrated on a single
joystick.

Equipped with a touch screen, each parameter can be visualized and viewed, and there are buttons under the screen to operate, and
the parameters can be adjusted according to the working conditions at any time.

The rotary platform has a built-in hydraulic rotary joint to prevent the hydraulic pipe from rotating and squeezing and bursting.

The extra-long auxiliary ladder has a length of 5 meters, which makes the transportation up and down more stable and the working
angle range larger.

The frame auxiliary beam is made of heightened and thickened longitudinal beams, and the overall tonnage of the frame reaches 2
tons, with solid materials, extremely high strength and better firmness. The upper and lower parts are fixed with 6 U-bolts and 5
high-strength U-shaped connecting plates, and the upper and lower connections are very firm.

The iron parts of the whole vehicle are made of high-strength plates, which are twice as strong as ordinary steel plates, and are
not easy to deform and crack.

Using a large 7-inch touch screen, as a new computer input device, it is currently the simplest, most convenient and natural way
of human-computer interaction, so that the operator's control is more intuitive, real-time reading of various parameters of the
control load and detailed alarm content, and the equipment debugging of various parameters set up in the shortest time to play the
performance of the equipment to the extreme, touch screen no operation when the intelligent standby, greatly improve the service
life of the touch screen.

The intelligent real-time monitoring system allows users to view the status of each component of the control system in real time,
so as to easily and quickly troubleshoot faults.
