High Speed S2000 F Glass Processing Machinery for Washing and Drying Glass

1.Three pairs of special designed air blade.Three pairs of air knives,two straight and one diagonal cross design.

2.Two blowers for selection, more choice to saving energy.1 straight + 1 inclined air blade structure which greatly improve the working of blow the water at the end corner glass away

3.Speed up to 16m/min

4.Modular assembled structure, aluminum alloy girders, touch screen +PLC control system, operating interface is simple and easy to understand.

5.Three pairs hair brush(Φ160 mm ) with stainless steel shaft, the up hard hair brush is controlled by pneumatic cylinder and can be lifted up independently, so the soft hair brush can wash the LOW-E glass, common coating film glass.

6.Helical teeth transmission driving system, frequency speed adjustment. The up and lower washing brushes are drive by two groups of independent gear belt system, with steady speed and longer working life.

7.Convenient thickness adjustment, the whole section can hoist 320mm to facilitate inner clean.

8 Can be standard with Feng Shui heating, temperature module collection, precise temperature control, energy saving, and high efficiency.

9 Can connected with high-speed double edging machine, automatic glass loading and unloading system to realize automatic processing.

10.Two pairs of air knives,one straight and one diagonal cross design.Inclined air blade structure which greatly improve the working of  blow the water at the end corner glass away
