Manufacturer Wholesale Low Price Custom Logo Stainless steel duplex buffer water tank for heat pump
- Category: >>>
- Supplier: Foshan Shengyu Thermal Energy Technology Co. Ltd.
Share on (1601153333294):
Product Overview
Description
Products Description
Manufacturer Wholesale Low Price Custom Logo Stainless steel duplex buffer water tank for heat pump
Capacity | L | 100 | 150 | 200 | 300 | 400 | 500 | 800 | 1000 | |||||||
Inner tank diameter | mm | Φ370 | Φ370 | Φ420 | Φ470 | Φ600 | Φ600 | Φ800 | Φ800 | |||||||
Out shell diameter | mm | Φ470 | Φ470 | Φ520 | Φ570 | Φ700 | Φ700 | Φ900 | Φ900 | |||||||
Out shell Height | mm | 1050 | 1490 | 1490 | 1490 | 1820 | 2160 | 1740 | 2090 | |||||||
Inner tank material | mm | SUS304 / SUS316L | ||||||||||||||
Out shell material | mm | galvanized steel with painting / stainless stell / PU | ||||||||||||||
Out shell color | white / silver-grey / blue /red / golden / stainless stell | |||||||||||||||
Max.working pressure | bar | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | |||||||
Max.testing pressure | bar | 10 | 10 | 10 | 10 | 10 | 10 | 10 | 10 | |||||||
Max.running temperature | ℃ | 90 | 90 | 90 | 90 | 90 | 90 | 90 | 90 | |||||||
Heating loss | W/K | 0.85 | 0.92 | 1.12 | 1.32 | 1.5 | 1.6 | 1.75 | 1.96 | |||||||
Standing loss | W | 30 | 33 | 40 | 46 | 52 | 57 | 65 | 70 | |||||||
ERP Class | C | C | C | C | C | C | C | C | ||||||||
Electrical heater | kw | 1.5 | 1.5 | 1.5 | 1.5 | 3 | 3 | 3 | 3 | |||||||
Mg.Anode rod | mm | Φ22*300 | ||||||||||||||
Water connection | G / BSP / NPT 3/4" | G / BSP / NPT 1" | ||||||||||||||
Packing size | mm | L:545 | L:545 | L:595 | L:630 | L:770 | L:770 | L:980 | L:980 | |||||||
W:545 | W:545 | W:595 | W:630 | W:770 | W:770 | W:980 | W:980 | |||||||||
H:1110 | H:1570 | H:1570 | H:1880 | H:1995 | H:2235 | H:1890 | H:2290 | |||||||||
* OEM/ODM avaiable.
* Being made of SUS304 or SUS316L Steel Stainless steel, anti-corrosion resistance.
* With optional built-in stainless steel corrugated coils.
* Tank type options:Vertical or Horizontal;Ground or wall mounted.
* 100L/150L/200L/300L/400L/500L/800L/1000Llager capacity choice.
* Work as buffer tank , storage tank ,.
* Electric heater and control box: 1KW,2KW,3KW，5KW are optional.
* Being made of SUS304 or SUS316L Steel Stainless steel, anti-corrosion resistance.
* With optional built-in stainless steel corrugated coils.
* Tank type options:Vertical or Horizontal;Ground or wall mounted.
* 100L/150L/200L/300L/400L/500L/800L/1000Llager capacity choice.
* Work as buffer tank , storage tank ,.
* Electric heater and control box: 1KW,2KW,3KW，5KW are optional.
