Smart kit Thermostat TRV Radiator heating Wireless Control Boiler Zigbee Gateway with sensor
- Category: >>>
- Supplier: Shenzhen Saswell Technology Inc.
Share on (1601156358440):
Product Overview
Description
Product Description
The gateway technical specification
| Power supply | 5V=1A |
| Working temperature | -10~55°C |
| Working humidity | 10~90%RH (non condensation) |
| Wireless technology | 2.4Ghz WIFI,Zigbee |
| Dimension | 60.5*60.5*16.1mm |
The thermostat technicial specification
| Power supply | 2x1.5V AA alkaline batteries(LR6) |
| Battery life | 1 year |
| Temperature display | 0~50°C |
| Temperature setting range | 5~30°C |
| Temperature display accuracy | 0.5°C |
| Storage temperature & humidity | -10~60°C, 25~90%RH(non condensation) |
| Operation temperaure & humidity | 0~50°C, 25~90% RH(non condensation) |
The TRV technical specification
| Power supply | 2x1.5V AA alkaline batteries(LR6) |
| Battery life | 1 year |
| Temperature display | 0~50°C |
| Temperature setting accuracy | 5~30°C |
| Temperature display accuracy | 0.5°C |
| Wireless transmit range | Open 30m in the air |
| Frequency | 2.4GHz |
| Storage temperature & humidity | -10~60°C,25~90%RH (non condensation) |
| Operation temperature & humidity | 0~50°C, 25~90% RH (non condensation) |
It can connect several TRV ( no over 10pcs is better)
Packaging & Shipping
TVR
55*95.2mm
Gateway
60.5*60.5*16.1mm
Company Information
SASWELL is a research and development technology company with innovative technology driving in thermostats. It was established in 2003. The R&D center and manufacturing center are both located in Shenzhen. In the past 20 years, it has provided indoor thermostat ODM services for more than 100 large enterprises. Strong independent research and development capabilities, obtained ISO9001 quality certification, BSCI business social code of conduct certification, Germany Rheinland TUV certification and many other technical certifications, with many independent research and development technology products, including system control logic, bus control technology, short-distance wireless communication technology, etc. , and become an ecological partner of Tuya Cloud, Alibaba Cloud, Tencent Cloud, and Huawei Cloud, and has been widely recognized by global customers such as Asia Pacific, Middle East, Northern Europe, Eastern Europe, Russia, and the United States.
