Factory Hot Selling stainless steel threaded union type 10.0mpa threaded expansion joint
- Category: >>>
- Supplier: Henan Chnflex Industrial Co. Ltd.
Share on (1601159602293):
Product Overview
Description
Product Description
The bellows expansion joint is composed of elastic rubber joints, flat movable joints, loose metal flanges or threaded pipe flanges, used for vibration isolation, noise reduction, and displacement compensation. It is a pipeline joint with high elasticity, high airtightness, moderate resistance, and weather resistance. The joint is composed of inner rubber, polyester cord reinforcement layer, outer rubber, and composite hose. The frame layer is made of polyester fabric, and the reinforcement layer has a steel ring.
Functions
1. High pressure
2. Good elasticity
3. Large deflection
4. Good anti-aging performance
5. Good vibration damping performance
Technology
Main data of threaded expansion joint | ||||||
Nominal diameter(DN) | Length | Axial displacement(mm) | Horizontal displacement | Deflexion angle | ||
mm | inch | mm | Extension | Compression | mm | (a1+a2)° |
15 | 1/2 | 200 | 5-6 | 22 | 22 | 45° |
20 | 3/4 | 200 | 5-6 | 22 | 22 | 45° |
25 | 1 | 200 | 5-6 | 22 | 22 | 45° |
32 | 1 1/4 | 200 | 5-6 | 22 | 22 | 45° |
40 | 1 1/2 | 200 | 5-6 | 22 | 22 | 45° |
50 | 2 | 200 | 5-6 | 22 | 22 | 45° |
65 | 2 1/2 | 265 | 8-10 | 24 | 24 | 45° |
80 | 3 | 285 | 8-10 | 24 | 24 | 45° |
Detailed Images
Production Flow
It is very important to select the appropriate flexible rubber expansion joint of the pipeline, understand the compatibility of the medium with the selected material, the full temperature, pressure and vacuum range, the required movement and the size between the pipeline flanges. With this information, Jingning application engineers can help determine the ideal expansion joint for any application.
Hot products
Advantages
1.Factory price
2.20 years of manufacturing experience, 8 years of export experience
3.Strict quality inspection, the quality far exceeds the industry standard.
4.Mold a variety of specifications, support customization, OEM
5.Provide free samples
6.Large inventory
Product Uses
Threaded rubber expansion joint can be widely used in water supply and drainage, circulating water, HVAC, fire protection, paper making, pharmaceutical, petrochemical, ship piping system, water pump, compressor, fan and other piping systems. Ordinary threaded rubber expansion joint is used to transport - 15 ℃ - 115 ℃ air, compressed air, water, water, seawater, oil, acid and alkali. Special type threaded rubber expansion joint is used to transport medium, oil or strong alkali, strong acid and solid materials above - 30 ° C to 250 ° C.
Certifications
FAQ
Q1: Can the bellows expansion joint be customized with identification?
A1: Sure, we provide OEM and ODM services.
Q2: What is the face-to-face length of the bellows expansion joint?
A2: We can also accept customized lengths according to your requirements.
Q3: Can you provide the product drawings?
A3: Yes, we can provide you with drawings. Please contact us to obtain the drawings of the bellows expansion joint.
Q4: What certificates can you provide for bellows expansion joints?
A4: We can provide CE and ISO certificates.
