Product Overview
Description
Product Description
Material:
All 304 stainless steelAll 201 stainless steel
External baking paint and internal 304 stainless steel
Function
Pass box is a corollary equipment in clean room,instead between the area which has different clean grade,used to transfer
goods,though the goods can self-purifation,it can used as the air brake,prevent the air convection between the clean room.
The electronic interlocking equipment,which makes the doors on two side can't open at the same time,that ensure the air in the clean area can't convect. After putting the goods in the box,close the door,start air shower,when reach the setting time,the doors can open,then ensure the goods' cleanliess.
Sturctural features
The case made of ss,which can avoid the rustiness effectively.
Electronic interlocking,the two doors can't open at the same time.
The two doors all use double glazing glass,surfacting,dust accmulate difficulty,easy to clean.
The two doors all embedded in the case,surfacing,dust accumulate difficulty,easy to clean.
The four corners inside are circular arc structure,easy to clean and sterilize.
Equipment with differnetial pressure gauge and DOP test port.
Parameter
Filter efficiency≥99.99%(Na flame method)@0.5μm
Clean time:0-99s adjustable(acquiesce in 15s)
Clean air speed:0.36-0.54m/s
UV light:30W
Power:single AC220V 50Hz
Customized
Operating features :
1: clean pass boxes is manufactured for the most demanding controlled environment applications.
2: All components are designed for maximum chemical resistance and enhanced durability for a long service life.
3: clean pass boxes is constructed of stainless steel inside, making the work zone easy to clean and endurable.
4:Mechanical and electric interlock are reliable, maintenance-free, maintains clean room integrity by preventing both door from being opened and the same time.
Pass box is a corollary equipment in clean room,instead between the area which has different clean grade,used to transfer
goods,though the goods can self-purifation,it can used as the air brake,prevent the air convection between the clean room.
The electronic interlocking equipment,which makes the doors on two side can't open at the same time,that ensure the air in the clean area can't convect. After putting the goods in the box,close the door,start air shower,when reach the setting time,the doors can open,then ensure the goods' cleanliess.
Sturctural features
The case made of ss,which can avoid the rustiness effectively.
Electronic interlocking,the two doors can't open at the same time.
The two doors all use double glazing glass,surfacting,dust accmulate difficulty,easy to clean.
The two doors all embedded in the case,surfacing,dust accumulate difficulty,easy to clean.
The four corners inside are circular arc structure,easy to clean and sterilize.
Equipment with differnetial pressure gauge and DOP test port.
Parameter
Filter efficiency≥99.99%(Na flame method)@0.5μm
Clean time:0-99s adjustable(acquiesce in 15s)
Clean air speed:0.36-0.54m/s
UV light:30W
Power:single AC220V 50Hz
Customized
Operating features :
1: clean pass boxes is manufactured for the most demanding controlled environment applications.
2: All components are designed for maximum chemical resistance and enhanced durability for a long service life.
3: clean pass boxes is constructed of stainless steel inside, making the work zone easy to clean and endurable.
4:Mechanical and electric interlock are reliable, maintenance-free, maintains clean room integrity by preventing both door from being opened and the same time.
Title goes here.
Semi-Automatic PET Bottle Blowing Machine Bottle Making Machine Bottle Moulding Machine
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
PET Bottle Making Machine is suitable for producing PET plastic containers and bottles in all shapes.
Detail Images
A.The box body is made of high quality steel with surface spray and without dust.
B. The liner is stainless steel, smooth and easy to clean.
c.Unique design of arc door , beautiful and easy to clean.
B. The liner is stainless steel, smooth and easy to clean.
c.Unique design of arc door , beautiful and easy to clean.
D. Non-baffle high efficiency filter, the filtering efficiency of dust particles at 0.3 cleaning m is 99.99%
E. Maintain noise below 60 dB (A) at work.
F.Permanent lubrication of the centrifugal fan.
E. Maintain noise below 60 dB (A) at work.
F.Permanent lubrication of the centrifugal fan.
G.Stainless steel nozzles provide high velocity air to remove dust particles effectively.
H. Electronic interlocking system prevents internal and external air flow through.
I. special sealing strip is installed to ensure air tightness.
H. Electronic interlocking system prevents internal and external air flow through.
I. special sealing strip is installed to ensure air tightness.
J. Simple installation and good clean room compatibility.
K. Mechanical or electronic interlocking systems and structural reinforcement design ensure safety.
L. Simple installation and good clean room compatibility.
K. Mechanical or electronic interlocking systems and structural reinforcement design ensure safety.
L. Simple installation and good clean room compatibility.
More Types
PASS BOX
Model | P500 |
Inside size W*D*H | 500*500*500MM |
Outside size W*D*H | 660*560*600MM |
Cleanliness | Grade A class100 |
Voltage | AC 220V 50HZ |
Interlock type | mechnical interlock or electric interlock |
Material | All 304 stainless steel All 201 stainless steel External baking paint and internal 304 stainless steel |
AIR SHOWER PASS BOX
Model | P500 |
Inside size W*D*H | 500*500*500MM |
Outside size W*D*H | 660*590*1390MM |
Noise | <65db |
Showing time | 0-99min(adj) |
Voltage | AC 220V 50HZ |
LAMINAR PASS BOX
Model | P500 |
Inside size W*D*H | 500*500*500MM |
Outside size W*D*H | 700*580*1100MM |
HEPA filter size | 330*280*90MM |
Motor power | 300 |
Air speed(m/s) | 0.45+20% |
Cleanliness | Grade A class100 |
Noise | <65db |
Showing time | 0-99min(adj) |
Voltage | AC 220V 50HZ |
Application
100 Labl Laboratory Clean Room Hospital Pass Through Box with UV lamp
