P1.2 Small Pixel Pitch Indoor LED Screen For Radio / Television Studio
- Category: >>>
- Supplier: ShenZhen Highmight Technology Co. Ltd
Share on (1601162208428):
Product Overview
Description
LED small pitch(HMT-XA) series | ||||||||||
Model | HMT-XA0.9 | HMT-XA1.2 | HMT-XA1.5 | HMT-XA1.8 | HMT-XA2.3 | |||||
Pixel pitch | 0.9375(mm) | 1.25(mm) | 1.5625(mm) | 1.875(mm) | 2.34(mm) | |||||
Module Size | 300x168.75(mm) | 300x168.75(mm) | 300x168.75(mm) | 300x168.75(mm) | 300x168.75(mm) | |||||
Module pixel | 320x180 | 240x135 | 192x108 | 160x90 | 128x72 | |||||
Density pixel | 1137778(dot/m) | 640000(dot/㎡) | 409600(dot/ ㎡) | 284444(dot/ ㎡)) | 182044(dot/ ㎡) | |||||
Lamp bead model | MINl4in1 | SMD1010 | SMD1212 | SMD1515 | SMD1515/2020 | |||||
Brightness | 500-800(cd/㎡) | 500-800(cd/㎡) | 500-800(cd/㎡) | 500-800(cd/㎡) | 500-800(cd/㎡) | |||||
Refresh rate | 3840(Hz) | 3840(Hz) | 3840(Hz) | 1920/3840(Hz) | 1920/3840(Hz) | |||||
Scanning mode | 1/60S | 1/45S | 1/54S | 1/45S | 1/36S | |||||
Pcb thickness | 1.6(mm) | 1.6(mm) | 1.6(mm) | 1.6(mm) | 1.6(mm) | |||||
Overal Size | 600x337.5(mm) | 600x337.5(mm) | 600x337.5(mm) | 600x337.5(mm) | 600x337.5(mm) | |||||
Overall pixel | 640x360 | 480x270 | 384x216 | 320x180 | 256x144 | |||||
Overall thickness | 32.5mm | |||||||||
Service life | >=100000 hours | |||||||||
Contrast ratio | >=5000:1 | |||||||||
Colour temperature | 2000-9500K Adjustable | |||||||||
Grayscale | 16bit | |||||||||
Maximum power | 600-800(w/㎡) | |||||||||
Average power | 400-600(w/㎡) | |||||||||
input voltage | AC100-240V 50/60HZ | |||||||||
Module voltage | DC4.7-5V±0.2V | |||||||||
Environment | temperature-10-40℃ humidity10%-90% | |||||||||
Weight | 7.8(kg/PCS) | |||||||||
Material quality | Die-casting Aluminum | |||||||||
Maintenance | Front maintenance | |||||||||
Installation | Sitting installation | |||||||||
