OBO S5 D5 Plaster Spraying machinery 2024 Hot selling Factory direct sale small Portable Electric Cement Mortar Spray Machine
- Category: >>>
- Supplier: Fuzhou Shany Machinery Co. Ltd.Fuzhou Ltd.
Share on (1601162627801):
Product Overview
Description
Product Overview
Cement Mortar Plastering Machine
Screw spray machine commonly known as multi-function spray machine, it is through the motor to turn the screw, the paint is squeezed into the spray gun, and then through high pressure air injection, to achieve rapid paint on the wall.
It is a new type of liquid conveying machine, which has the advantages of simple structure, safe work, convenient operation and maintenance, continuous and uniform liquid production.
It can be sprayed with a wide range of building materials, generally 6mm below the particles can be sprayed, such as: plaster gypsum, anti-crack mortar, real stone paint, cement mortar, thick fireproof paint and so on.
It is a new type of liquid conveying machine, which has the advantages of simple structure, safe work, convenient operation and maintenance, continuous and uniform liquid production.
It can be sprayed with a wide range of building materials, generally 6mm below the particles can be sprayed, such as: plaster gypsum, anti-crack mortar, real stone paint, cement mortar, thick fireproof paint and so on.
FEATURES AT A GLANCE
back
front
side
PRODUCT SPECIFICATIONS
Item Name: | cement mortar spraying machine single spray tubel | ||||||
Model: | S5-D5 double gun | ||||||
Voltage（V): | 220/380/110V | ||||||
Motor power(kw): | 1.8 | ||||||
Max particles(mm): | 3 | ||||||
Length of high pressure hose(M): | 5 | ||||||
Hopper capacity（L) | 60 | ||||||
Max working pressure (Mpa): | 2 | ||||||
Max. horizontal conveying distance（M): | 13 | ||||||
Max. vertical conveying distance（M): | 8 | ||||||
Working Air compressor power : | 7500W- 1.0/12.5 | ||||||
Power source: | Electric | ||||||
N.W （Kgs): | 36 | ||||||
G.W （KG): | 72 | ||||||
Carton Size(cm): | 106*54*80 | ||||||
PRODUCT CONFIGURATION
Recommend Products
FAQ
Q1:WHAT IS YOUR DELIVERY TIME?
A1:3-7 days for the sample order, 25~30 days for the mass orders.
Q2:WHAT IS YOUR WARRANTY TERM?
A2:12 months warranty for main components(like Motor,pump and system.)
Q3:CAN YOU ACCEPT OEM SERVICE?
A3: Yes
Q4: WHAT’S THE PAYMENT TERM?
A4:Sample order, 100% before shipment. mass order, 30% deposit,balance against copy of BL.
Q5:What is your after-sale service?
A5:We will send you free replacement if parts are guaranteed in 12 months
