HeltecEnergy Long cycle UAV high C rating 50C 60C 22.2V 14.8V 11.1V 7.4V 22000mAh 25C 35C NMC Li ion Battery for Drone and UAV
- Category: >>>
- Supplier: Chengdu Heltec Energy Technology Co. Ltd.
Share on (1601165758964):
Product Overview
Description
Product Description
Model Selection
Capacity | Assemble | Voltage | Discharge Rate | Battery Size | Weight | Plug socket |
22000mAh | 2S1P | 7.4V | Standard:25C Customizable | 202*90*22mm | 795g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 202*90*32mm | 1189g | |||
4S1P | 14.8V | 202*90*42mm | 1586g | |||
6S1P | 22.2V | 202*90*62mm | 2400g | |||
16000mAh | 2S1P | 7.4V | Standard:25C Customizable | 182*74*23mm | 490g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 182*74*33mm | 734g | |||
4S1P | 14.8V | 182*74*43mm | 978g | |||
6S1P | 22.2V | 182*74*63mm | 1468g | |||
12000mAh | 2S1P | 7.4V | Standard:25C Customizable | 182*74*21mm | 578g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 182*74*31mm | 866g | |||
4S1P | 14.8V | 182*74*41mm | 115g | |||
6S1P | 22.2V | 182*74*61mm | 1732g | |||
10000mAh | 2S1P | 7.4V | Standard:25C Customizable | 165*66*21mm | 490g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 165*66*31mm | 734g | |||
4S1P | 14.8V | 165*66*41mm | 978g | |||
6S1P | 22.2V | 165*66*61mm | 1468g |
Capacity | Assemble | Voltage | Discharge Rate | Battery Size | Weight | Plug socket |
8000mAh | 2S1P | 7.4V | Standard:35C Customizable | 165*66*21mm | 490g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 165*66*31mm | 734g | |||
4S1P | 14.8V | 165*66*41mm | 978g | |||
6S1P | 22.2V | 165*66*61mm | 1468g | |||
8000mAh | 2S1P | 7.4V | Standard:35C Customizable | 165*56*22mm | 425g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 165*56*32mm | 635g | |||
4S1P | 14.8V | 165*56*42mm | 845g | |||
6S1P | 22.2V | 165*56*62mm | 1265g | |||
7000mAh | 2S1P | 7.4V | Standard:35C Customizable | 158*46*21mm | 295g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 158*46*31mm | 440g | |||
4S1P | 14.8V | 158*46*41mm | 580g | |||
6S1P | 22.2V | 158*46*61mm | 880g | |||
6000mAh | 2S1P | 7.4V | Standard:35C Customizable | 148*46*20mm | 270g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 148*46*30mm | 405g | |||
4S1P | 14.8V | 148*46*40mm | 540g | |||
6S1P | 22.2V | 148*46*60mm | 810g |
Capacity | Assemble | Voltage | Discharge Rate | Battery Size | Weight | Plug socket |
5200mAh | 2S1P | 7.4V | Standard:35C Customizable | 138*42*20mm | 263g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 138*42*30mm | 395g | |||
4S1P | 14.8V | 138*42*40mm | 526g | |||
6S1P | 22.2V | 138*42*60mm | 785g | |||
4200mAh | 2S1P | 7.4V | Standard:35C Customizable | 138*43*17mm | 205g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 138*43*25mm | 310g | |||
4S1P | 14.8V | 138*43*33mm | 412g | |||
6S1P | 22.2V | 138*43*49mm | 620g | |||
3200mAh | 2S1P | 7.4V | Standard:35C Customizable | 138*42*14mm | 170g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 138*42*21mm | 255g | |||
4S1P | 14.8V | 158*46*28mm | 340g | |||
6S1P | 22.2V | 138*42*42mm | 510g | |||
2800mAh | 2S1P | 7.4V | Standard:35C Customizable | 120*36*16mm | 150g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 120*36*16mm | 405g | |||
4S1P | 14.8V | 120*36*16mm | 540g | |||
6S1P | 22.2V | 120*36*16mm | 810g |
Capacity | Assemble | Voltage | Discharge Rate | Battery Size | Weight | Plug socket |
2200mAh | 2S1P | 7.4V | Standard:35C Customizable | 106*34*16mm | 120g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 106*34*24mm | 180g | |||
4S1P | 14.8V | 106*34*32mm | 240g | |||
6S1P | 22.2V | 106*34*48mm | 360g | |||
1800mAh | 2S1P | 7.4V | Standard:35C Customizable | 106*34*14mm | 110g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 106*34*21mm | 165g | |||
4S1P | 14.8V | 106*34*28mm | 220g | |||
6S1P | 22.2V | 106*34*42mm | 330g | |||
1550mAh | 2S1P | 7.4V | Standard:35C Customizable | 75*35*17mm | 82g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 75*35*24mm | 123g | |||
4S1P | 14.8V | 75*35*33mm | 164g | |||
6S1P | 22.2V | 75*35*50mm | 246g | |||
1300mAh | 2S1P | 7.4V | Standard:35C Customizable | 80*35*12mm | 65g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 80*35*18mm | 97g | |||
4S1P | 14.8V | 80*35*24mm | 130 | |||
6S1P | 22.2V | 80*35*36mm | 195g |
Capacity | Assemble | Voltage | Discharge Rate | Battery Size | Weight | Plug socket |
1100mAh | 2S1P | 7.4V | Standard:35C Customizable | 75*35*11mm | 62g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 75*35*16mm | 93g | |||
4S1P | 14.8V | 75*35*22mm | 124g | |||
6S1P | 22.2V | 75*35*33mm | 186g | |||
900mAh | 2S1P | 7.4V | Standard:35C Customizable | 58*30*14mm | 58g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 58*30*24mm | 86g | |||
4S1P | 14.8V | 58*30*32mm | 115g | |||
6S1P | 22.2V | 58*30*48mm | 172g | |||
550mAh | 2S1P | 7.4V | Standard:35C Customizable | 50*25*14mm | 42g | T Plug XT60 plug Customizable |
3S1P | 11.1V | 50*25*22mm | 62g | |||
4S1P | 14.8V | 50*25*32mm | 84g | |||
6S1P | 22.2V | 50*25*48mm | 126g |
Specification
Long cycle UAV high C-rating 25C 35C 6S 4S 3S 2S 22.2V 14.8V 11.1V 7.4V
550mAh-22000mAh lipo battery for agriculture drone and UAV
For other capacity and strings,please contact us directly
Caution
1.Please ensure to use a specially balanced charger for charging.
2.Lithium batteries should not be fully charged and stored for extended periods of time,
Long term storage and use can easily cause inflation. The optimal storage voltage that affects discharge performance is around 3.8V per chip.Fill before use and reuse.Can
effectively avoid battery inflation phenomenon.
3.Lithium batteries should not exceed their designed maximum discharge C (overcurrent discharge)Overdischarge can seriously affect the performance of the battery or directly lead to battery damage.
4.Once the battery expands, do not use sharp metal objects to penetrate and deflate it.Can cause internal short circuits in the battery, leading to battery explosion or combustion.
Details & Images
FAQ
1. Can you accept customization?
A: Yes, our company has a design department. We provide hardware design, ARM and Mbed system software design, etc. If you want to know more about our service, please click here: why choose us.
2. How long will it take for sample making and mass production?
A: It takes about 3-5 days to make the sample, and 7-30 days for mass production.
3.How about the productivity of your company?
A: We have enough storage for most of our products, if you need customize we have SMT factory to fulfill your needs after you pay for the products.
4.What about the mode of transportation ?
A: According to the quantity and volume, we will choose the most suitable and cost-effective way of transportation for you. Of course, you are also free to choose the most convenient one.
5.How do you guarantee the quality of your products?
A: We have professional instruments and equipment for development and test, and we use manual inspection. Each product will be tested before packaging.
Packing & Shipping
Company Profile
Chengdu Heltec Energy Technology Co., Ltd, as known as HeltecBMS, is one professional manufacture located in Chengdu, Sichuan, China. We focus on battery management system for many years. We design, produce, and sell hardware BMS, Smart BMS, Active Balancer, battery welding machine, battery maintenance and test instruments and other accessories. All these products are widely used in lithium battery industry.
We have strong technical R&D teams, scientific production platform and strict quality control system that allow us to provide all kinds of services including BMS design and manufacturing, sample orders and batch orders, OEM and ODM orders. We have professional engineer support, high efficiency sales team and reliable quality products that attract customers from all over the world. We are honored as the excellent supplier of many companies all around the world including Europe, USA, Canada, Australia, Brazil, Japan, Korea and South Africa.
We are reliable supplier of the battery management system industry with 1 year warranty. We deeply believe that on the road to innovation, we are not standing still. We constantly, with reliable quality requirements, to meet the market demand as the goal, development and production of exquisite appearance, excellent performance, energy conservation and environmental protection green products, is committed to be a leader in the market. We welcome new and old customers from all walks of life to contact us for future business relationships and mutual success.
