New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer
New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer
New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer
New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer
New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer
New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer
New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer

New Type Hot Sale 360 degree Rotation 30 degree Tilt Various Types Of Piles Driven Side Grip Vibro Hammer

Share on (1601167329159):


Price:$64,000.00-65,000.00

Quantity:


Product Overview

Description





ANTENG side grip pile drivers are excavator-mounted, high frequency, vibratory-type pile drivers - for handling, pitching, driving and extracting different type of piles in a wide range of site and soil conditions.






FEATURES:
1. Full hydraulic flexible control, simple operation, 360° rotation, 30° tilt , pick up pile easily
2. No need to modify excavator, install and use easily
3. Limited space is available
4.Available for a wide range of piles including sheet piles, H-piles, tubular steel piles, timber piles etc.
5. Precise ,safe, stable ,efficient, and economical, core components are imported from famous brands






Eccentric Moment
Kgm
6.5
Centrifugal force
Kn
585
Max. Centrifugal force
Kn
650
Frequency
Rpm
2400-3000
Side clamp force
Kn
912
Bottom clamp force
Kn
650
Hydraulic system operation pressure
bar
320
Rotate/tilt degree
°
360/+-30
Size
mm
1350*1490*2650
Weight
Kg
3200
Applicable excavator class
Ton
32-40


AT-65B Application：
*AT-65B Designed to match the capabilities of large excavators and to combine a robust structure with excellent pile handling characteristics.
* Fitted with clamps capable of driving a wide range of piles including sheet piles, H-piles, tubular steel piles and other pile section
