HUAYUAN T315 6 90sqm Hydraulic Mobile Event Stage Truck For Outdoor Activities Campaigns Elections Evangelism
- Category: >>>
- Supplier: Henan Cimc Huayuan Technology Co. Ltd
Share on (1601167480264):
Product Overview
Description
stage truck
NEW P5/P6/P8/P10 display screen for mobile roadshow stage trailer
Product discription
Mobile stage trailer is a kind of multi-functional special vehicle, which has been used in various performances,
advertisingroad shows and publicity activities, with thecharacteristics of convenient and flexible.
Choose this stage car with strong usability,which will definitely bring higher quality to your activities.
The vehicle can be turned into a stage.The car body can be divided into three expansion forms: one side,
two sides and three sides.The normally expanded space is 64cbm, and the normally enlarged space is 84cbm.
Technical Paremeters
stage | Box size (L × W × H ) | 9600×2500×--mm |
| Stage size (mm) | Depth: 4880-7230; Opening width: 9000-14780; Ground clearance: 1400 |
| Stage area | 64 - 84 (square metres) |
| Stage steps | Aluminum pattern pedal + armrest |
| Stage support | The stage legs are stored in the space below the stage skeleton, and can be directly screwed out and fixed. |
| Extended connection | The hinge is articulated with the main stage board, which can be flipped manually and become a part of the stage. |
| Chassis legs | Hydraulic outrigger |
| Wings, main and auxiliary stage, ceiling | Hydraulic deployment |
| Left background | Hydraulic deployment |
Chassis | Chassis model | HFC1251P2K3D54S1V |
| Emission Standards | GB17691-2005, GB3847-2005 |
| Power (kw) | 179(240PS) |
| Chassis configuration | Air conditioners, airbag seats, on-board tools, fire extinguishers, warning triangles, semi-high roof cabs |
| Displacement | 6740mL |
| Tires | 11.00R20,12R22.5 |
vehicle | Overall dimensions of the vehicle (L × W × H ) |
|
| Total vehicle mass (kg) | 19500 |
| Load capacity (kg) | 2000 |
LED screen (optional) | The size is 8640 * 2880, the screen body is folded or closed by hydraulic pressure (optional) | |
Detail Pictures
Structure Description
1. The overall body adopts aluminum alloy profile, steel profile and stamping parts skeleton, and the outer skin is aluminum alloy plate;The stage floor is an anti-skid laminated stage board;The right wing of the car body and the roof are lifted by the hydraulic system as the roof for the stage to shield the sun and rain.
2. Switchboards, lighting, stage lighting lines and power sockets shall be installed inside the car body. The specific requirements for access sockets and power distribution layout shall be put forward by the demander and constructed by the supplier.
3. All the light pylons in the stage roof are trusses, and two support trusses are set at the outermost end of the wing plate in the direction of the platform entrance.Each end of the inner wing plate is provided with a background hanging cross rod
3. The power of the hydraulic system is taken from the engine and is independent power unit. The operation is remote control + electronic control
Company Information
Company Information
Henan CIMC Huayuan Vehicle Co., Ltd., located in Changge City, Henan Province, China, was founded in 2008. It is mainly engaged in mobile stage vehicles, LED vehicles, roadshow vehicles, wing-open vans, mobile sales vehicles, etc. Development, production, sales and related customized services and services for vehicles and their components.The Huayuan brand mobile stage vehicles, touring exhibition vehicles and mobile sales vehicles developed and produced by us have beautiful appearance, reasonable structure, safe use and strong carrying capacity . Mainly exported to Uzbekistan, the United Arab Emirates, Indonesia, New Zealand, Southeast Asia, Central America, South America and other countries and regions. Over the years, our various special vehicles have been well received by customers at home and abroad for their excellent quality and superior price.
Packaging & Shipping
1,Shipping term:whole vehicle or in parts,by container or by bulk,standard seaworthy wooden boxes are available.
2,Delivery time:10-15 days after deposit.
3,Delivery term:EXW,FOB,CFR,CIF etc.
