Programmable 3G/4G/WIFI Waterproof Sign Message LED Screen Car Advertising Taxi Roof Taxi Top LED Display Screen

Technical parameters

Parameters values

Pixel pitch

5mm

Panel size

L320mm×H160mm

Physical density

40000dots/sqm

Pixel configuration

1R,1G,1B

Driving method

Constant current

Scan mode

1/8 scan

LED Encapsulation

SMD2727/SMD2525

Display resolution

64dots×32dots=2048dots

Module weight

0.5KG

Module port

HUB75

Module working voltage

DC5V

Module consumption

21W

Cabinet size

640mm×640mm/960mm×960mm

Cabinet weight

7.5kg

Cabinet resolution

128dots×128dots /192dots×192dots

Viewing angle

160°

Option distance

5m-50m

Driving device

16016

Every square meter module

19.53pcs

Maximum power

850W/sqm

Frame Frequency

≥60HZ/S

Refresh frequency

≥1920HZ/S

Equilibrium brightness

≥5500CD/sqm

Working environment temperature

-10°C~60°C

Working environment humidity

10%~70%

Display working voltage

AC46~54HZ,220V±15%/110V±15%

Color temperature

8500K-11500K

Gray scale/color

≥16.7M color

Input signal

RF\\ S-Video\\ RGB etc

Control system

PCTV nonlinearity card, DVI display card,Linsn control system

Mean free error time

>5000

Life

100000

 Lamp failure frequency

<0.0001

Antijam

IEC801

Safety

GB4793

Resist the electricity

1500V last 1min No breakdown

IP rating

The front IP65
