Tobee Effluent Handling
$12,600
Tailored SV Single Stage Medical Vacuum Pump 100m3/h Horizontal Tank CVS 1*100 Model Medical Rotary Vane Vacuum System
- Category: >>>
- Supplier: Taizhou Shouzhen Machinery Co. Ltd.
Share on (1601169716802):
Product Overview
Description
ABOUT SOUZ PUMP
SOUZ VACUUM is a comprehensive high-tech enterprises integrating R&D, production, sales and service of vacuum pumps. With professional technical team to help every customer to get the most suitable and cost-effective vacuum solutions and vacuum pumps.
We always perseveres in innovative work to develop better products.
SOUZ VACUUM,covering an area of 100000 square meters production plant ,has hundreds of employees and 50 sets modern processing equipments.
Moreover, on the basis of digestion of imported Germany technology and substitution with SOUZ VACUUM improved technology. The key components of vacuum pump were choosen from international well-known brands to make the overall performance to achieve the international level. We can provide alternative basically spare parts to some well-known brands of vacuum pumps.
The acceptance rate of product will be raised by improvement of process's quality control.
We always perseveres in innovative work to develop better products.
SOUZ VACUUM,covering an area of 100000 square meters production plant ,has hundreds of employees and 50 sets modern processing equipments.
Moreover, on the basis of digestion of imported Germany technology and substitution with SOUZ VACUUM improved technology. The key components of vacuum pump were choosen from international well-known brands to make the overall performance to achieve the international level. We can provide alternative basically spare parts to some well-known brands of vacuum pumps.
The acceptance rate of product will be raised by improvement of process's quality control.
Medical Vacuum Pump Systems
A medical vacuum pump system is a type of equipment that uses a vacuum pump to generate a negative pressure environment, which is used for a variety of medical purposes. Medical vacuum systems are often used in hospitals and other healthcare facilities to provide suction for various procedures, such as removing mucus or other fluids from the airways of patients, draining wound fluids, and assisting with surgery.
Medical vacuum systems typically consist of a vacuum pump, a gas receiver/collection canister, and a connection pipeline that connects the pump to the gas receiver , inlet vacuum filter , vacuum gauge and vacuum switch etc. The vacuum pump generates a negative pressure environment.
Medical vacuum systems typically consist of a vacuum pump, a gas receiver/collection canister, and a connection pipeline that connects the pump to the gas receiver , inlet vacuum filter , vacuum gauge and vacuum switch etc. The vacuum pump generates a negative pressure environment.
AVAILABLE PUMP TECHNOLOGY
* Oil-Lubricated Rotary Vane Vacuum Systems
* Oil-Less Rotary Vane Vacuum Systems
* Oil-Lubricated Rotary Vane Vacuum Systems
* Oil-Less Rotary Vane Vacuum Systems
* 2BV Liquid Ring Vacuum Systems
SYSTEM CONFIGURATIONS
* Compact horizontal: integrated on horizontal receiver
* Compact vertical: integrated on a vertical steel frame
* Modular: separated modules to fit specific requirements
* In skids or shelters, according to customers' specifications
SYSTEM CONFIGURATIONS
* Compact horizontal: integrated on horizontal receiver
* Compact vertical: integrated on a vertical steel frame
* Modular: separated modules to fit specific requirements
* In skids or shelters, according to customers' specifications
Application:
Vacuum is essential for many OR and ICU procedures,multiple sizes and configurations available, select the system to meet both your code and size requirements.
CVS series advantage:
* CE certification
* Built-in oil mist filter, the air discharged does not contain oil mist.
* Strong air extraction, the ultimate vacuum degree can reach 0.01 Mbar (1Pa).
* The vacuum pump is lubricated with lubricating oil and has a long service life.
* Low noise, low vibration, and the working environment will not be affected.
* Excellent rust and corrosion resistance can form an effective anti-corrosion film on the metal surface.
* Minimal maintenance, Maximum Durability.
* Completely tested before shipment.
* CE certification
* Built-in oil mist filter, the air discharged does not contain oil mist.
* Strong air extraction, the ultimate vacuum degree can reach 0.01 Mbar (1Pa).
* The vacuum pump is lubricated with lubricating oil and has a long service life.
* Low noise, low vibration, and the working environment will not be affected.
* Excellent rust and corrosion resistance can form an effective anti-corrosion film on the metal surface.
* Minimal maintenance, Maximum Durability.
* Completely tested before shipment.
Customized Oil Lubricated Medical Vacuum Pump CVS Model Industrial Central VacuumSystem
Specification | ||||||
Description | Pump | Capacity | Receiver | |||
Duplex Horizontal Tank Mount | SV008 | 8-16m3/h | 0.06-0.3m3 | |||
SV010 | 10-20m3/h | 0.06-0.3m3 | ||||
SV020 | 20-40m3/h | 0.06-0.3m3 | ||||
SV040 | 40-80m3/h | 0.06-1m3 | ||||
SV063 | 63-126m3/h | 0.3-2m3 | ||||
SV100 | 100-200m3/h | 0.3-2m3 | ||||
SV140 | 140-280m3/h | 0.5-2m3 | ||||
SV160 | 160-320m3/h | 0.5-2m3 | ||||
SV200 | 200-400m3/h | 0.5-2m3 | ||||
SV250 | 250-500m3/h | 0.5-2m3 | ||||
SV300 | 300-600m3/h | 0.5-2m3 | ||||
Tailored SV Single Stage Medical Vacuum Pump 100m3/h Horizontal Tank CVS 1*100 Model Medical Rotary Vane Vacuum System
Model | Pumping capacity m3/h 50 HZ 60HZ | Vacuum pump | Amount | Pressure (MPA) | Each pump Power（KW） 50HZ 60HZ | Vacuum tank(m3) | ||||||||||
CVS-1X020 | 20 | 24 | SV-020 | 1 | 0~-0.1 | 0.90 | 0.90 | 0.06-0.2 | ||||||||
CVS-1X040 | 40 | 48 | SV-040 | 1 | 0~-0.1 | 1.5 | 1.5 | 0.06-0.2 | ||||||||
CVS-1X063 | 63 | 75 | SV-063 | 1 | 0~-0.1 | 2.2 | 2.2 | 0.06-0.2 | ||||||||
CVS-1X100 | 100 | 120 | SV-100 | 1 | 0~-0.1 | 3.0 | 3.0 | 0.06-0.2 | ||||||||
CVS-1X160 | 160 | 192 | SV-160 | 1 | 0~-0.1 | 4.0 | 5.5 | 0.3-2 | ||||||||
CVS-1X200 | 200 | 240 | SV-200 | 1 | 0~-0.1 | 5.5 | 5.5 | 0.3-2 | ||||||||
CVS-1X250 | 250 | 300 | SV-250 | 1 | 0~-0.1 | 5.5 | 7.5 | 0.3-2 | ||||||||
CVS-1X300 | 300 | 360 | SV-300 | 1 | 0~-0.1 | 7.5 | 7.5/9.0 | 0.3-2 | ||||||||
CVS-2X020 | 40 | 48 | SV-020 | 2 | 0~-0.1 | 0.90 | 0.90 | 0.06-0.3 | ||||||||
CVS-2X040 | 80 | 96 | SV-040 | 2 | 0~-0.1 | 1.5 | 1.5 | 0.06-1 | ||||||||
CVS-2X063 | 126 | 150 | SV-063 | 2 | 0~-0.1 | 2.2 | 2.2 | 0.3-2 | ||||||||
CVS-2X100 | 200 | 240 | SV-100 | 2 | 0~-0.1 | 3.0 | 3.0 | 0.3-2 | ||||||||
CVS-2X160 | 320 | 384 | SV-160 | 2 | 0~-0.1 | 4.0 | 5.5 | 0.5-2 | ||||||||
CVS-2X200 | 400 | 480 | SV-200 | 2 | 0~-0.1 | 5.5 | 5.5 | 0.5-2 | ||||||||
CVS-2X250 | 500 | 600 | SV-250 | 2 | 0~-0.1 | 5.5 | 7.5 | 0.5-2 | ||||||||
CVS-2X300 | 600 | 720 | SV-300 | 2 | 0~-0.1 | 7.5 | 7.5/9.0 | 0.5-2 | ||||||||
CVS-3X100 | 300 | 360 | SV-100 | 3 | 0~-0.1 | 3.0 | 3.0 | 0.5-2 | ||||||||
CVS-3X160 | 480 | 576 | SV-160 | 3 | 0~-0.1 | 4.0 | 5.5 | 0.5-2 | ||||||||
CVS-3X200 | 600 | 720 | SV-200 | 3 | 0~-0.1 | 5.5 | 5.5 | 0.5-2 | ||||||||
CVS-3X250 | 750 | 900 | SV-250 | 3 | 0~-0.1 | 5.5 | 7.5 | 0.5-2 | ||||||||
CVS-3X300 | 900 | 1080 | SV-300 | 3 | 0~-0.1 | 7.5 | 7.5/9.0 | 0.5-2 | ||||||||
IT CAN BE CUSTOMISED ACCORDING TO CUSTOMER'S SPECIAL REQUIREMENT. | ||||||||||||||||
Find More information from SOUZ VACUUM
Q1. What is the advantage about your company?
A1. Our company has professional team and professional production line.
Q2: Is it acceptable to make customers' own brand?
A2: Sure, we can do OEM.
Q3: What are your payment terms?
A3: 30% T/T deposit, 70% against documents, or L/C at sight.
Q4: How long is your warranty?
A4: One year!
Q5. Why should I choose your products?
A5. Compared to other VACUUM PUMPS' supplier in China, our products are better quality .
Q6. Any other good service your company can provide?
A6. Yes,we can provide good after-sale and fast delivery.
