CF450 8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function
CF450-8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function
CF450-8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function
CF450-8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function
CF450-8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function
CF450-8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function
CF450-8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function

CF450 8 GoPRINTo Units Printing Machine for Labels and Paper with Automatic Rewinding Function

Share on (1601171226992):


Price:$134,500.00 - $135,000.00

Quantity:


Product Overview

Description



Product Description




Specification


Model
CF450-8
Max feeding width
450mm
Printing width
430mm
Effective printing length
222~622 (70Z~196Z)
Speed
10-120m/min
Unwinding diameter
800mm
Rewinding diameter
800mm
Gear pitch
1/8 CP, Z=3.175mm
Plate thickness
1.14 or 1.7 optional
Double-sided thickness
0.38mm
Material weight
Paper 30-300 gsm, PET 12~60um, OPP 18~60um
Secondary registration precision
+/- 0.15 mm
Remote control
Equipped with remote diagnosis and remote service functions


Machine configurations:
-450mm width
-8 color servo driven printing unit
-IR dryer
-Each station with one big water chiller drum
-2 sets automatic tension controller
-3 set printing plate rollers
-1 set Ceramic anilox rollers
-1 set Chinese web guiding system
-Helical gear
-video monitor


Description
1. Easy change structure for plate loading or anilox roll
2. Fully electronic shaftless transmission, automatic pre-registration, automatic overprinting
3. High-precision clutch pressing method, the pressing position of plate roller and anilox roller is in place at one time
4. LED UV drying system, saving electricity and environmental protection
5. Easy operation, and low requirement on operator
6. Printing pressure: when exchange different repeat length printing roller, the printing pressure does not need to be adjusted
if the thickness of the printing material is the same
7. Automatic color registration: equipped with automatic pre-overprinting and automatic overprinting
8. Pre-registered electric eyes: Each printing unit equipped with one pre-registered electric eye.


 Equipments:
Electronic control and servo control
OMRON system(program electrical)
Motion Controller
NX102-1200 OMRON brand
Output module
NX-OD5121 OMRON brand
Input module
NX-ID5342 OMRON brand
Analog module
NX-AD2603 OMRON brand
Servo motor
MDMF202LIG6M OMRON brand
Driver
MEDLN83BE OMRON brand
Servo motor
MDMF202L1G6M OMRON brand
Driver
MFDLNA3BE OMRON brand
Encoder cable
10m * 6
Power cable
10m * 6


Optional acceccory machines and parts:
1.High precision plate mounting machine
2. Ultrasonic anilox cleaning machine
3. Core cutting machine
4. Roll loader
5. Operator lift to go up and down
6. Ceramic anilox roller
7. GPD-320 Flatbed die cutting machine
8. GPF-320 High speed slitting machine
9. GPFT-320 Full auto turret rewinding machine
10. Powder brake & clutch
11. Hydra jacks
12. Magnetic cylinder
      Solid cylinder
      Rotary sheeting cylinder
      Flexible die


Packing & Delivery


fumigated wooden box




Company Profile




WENZHOU GOPRINTO MACHINERY CO.,LTD is a professiona large-scale manufacturer of printing machine, and auxiliary machines related to labels and spare parts service. We have continuously tried to improve product quality, challenge with advanced innovations. Our main products include printing machine, rotary/flatbed die cutting machine, slitting machine, finishing machine, paper bag making machine ect. Our parent company was established in year 2017, and we have many years of history in the label industry. We have already exported to America, Germany, Russia and 20 other countries and regions. Our company has always focused on research, development and innovation, We regards"reasonable prices, efficient production time and good after-sales service" as our soul tenet. We hope to cooperate with more customers for mutual development and benefits. We welcome potential buyers to contact us.


FAQ


1. who are we?
We are based in Zhejiang, China, start from 2007,sell to North America(30.00%),Central America(20.00%),South America(10.00%),Western Europe(5.00%),Mid East(5.00%),Southern Europe(5.00%),Eastern Europe(5.00%),South Asia(5.00%),Northern Europe(5.00%),Southeast Asia(5.00%),Eastern Asia(2.00%),Africa(2.00%),Oceania(1.00%). There are total about 5-10 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
flexo printing machine,die cutting machine,slitting machine,fan folding machine,hot lamination machine

4. why should you buy from us not from other suppliers?
For before-order stage, our professional sales team could respond your inquiry within 5-10 minutes during working hours.For after-sale stage, our service team always keep close contact with you and always stand by at your service.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,CIP,FCA,DDP,DDU,DAF；
Accepted Payment Currency:USD,EUR,CNY;
Accepted Payment Type: T/T,L/C,Credit Card,PayPal,Western Union,Cash;
Language Spoken:English,Chinese
