China Supplier NBC 713UNV Battery operated Hydraulic Universal Tool Crimping cutting punching all round king crimping pliers
- Category: >>>
- Supplier: Beijing Tianze Electric Power Group Co. Ltd.
Share on (1601173876305):
Product Overview
Description
Product Description
Specification
item | value |
System Pressure | 70MPa |
Maximum Output | 130 kN (13.0 t) |
Dimensions | 421×94×353 mm |
Weight | 7.2 kg (Incl. Battery) |
Application | 1 Crimping: Cu & Al cable lugs and splicing sleeves up to 400mm², H-type and C-type clamps up to 240mm². 2 Cutting range: conductor cutter used for cutting ACSR 800mm², steel strand 150mm², steel wire rope φ 20mm, Cu & Al cable φ 40mm. 3 Punching: ordinary steel δ3.5mm: φ16-φ61.5 stainless steel δ2.5mm: φ16-φ61.5 |
1 The body is equipped with OLED display, which provides battery capacity, light switch, maintenance times, Bluetooth information etc.
2 The tool with a touch key, which can touch the screen to display information at any time
3 Built-in chip, with memory function, can stop automatically when crimping is completed, realize intelligent crimping.
4 Built-in high pressure relief valve which will release pressure and return oil automatically after reaching rated pressure.
5 Built-in work count function, which can add up to 200,000 times, and can be uploaded to the system through the data cable and Bluetooth.
6 The high-performance 18V Li-ion battery with large capacity can provide more number of crimping times.
7 The body shell is made of double-color injection molding, which is more sturdy and durable. Rubbers grip to have low noise and minimal vibration, making operation more comfortable.
8 The tool head can be rotated 180 degrees so that the cutting performance can be completed at any angle.
9 The battery is equipped with a battery capacity display. The operator can check the battery capacity at any time.
10 The power switch button and oil-return button are designed independently to prevent incorrect operation.
11 Double LED lights cover the entire crimping area to ensure night work.
12 The tool can realize oil-return function without power by pressing the oil-return button, one button pressed to release pressure and return oil.
Warning: Do not rotate the tool head when there is pressure in the hydraulic circuit.
2 The tool with a touch key, which can touch the screen to display information at any time
3 Built-in chip, with memory function, can stop automatically when crimping is completed, realize intelligent crimping.
4 Built-in high pressure relief valve which will release pressure and return oil automatically after reaching rated pressure.
5 Built-in work count function, which can add up to 200,000 times, and can be uploaded to the system through the data cable and Bluetooth.
6 The high-performance 18V Li-ion battery with large capacity can provide more number of crimping times.
7 The body shell is made of double-color injection molding, which is more sturdy and durable. Rubbers grip to have low noise and minimal vibration, making operation more comfortable.
8 The tool head can be rotated 180 degrees so that the cutting performance can be completed at any angle.
9 The battery is equipped with a battery capacity display. The operator can check the battery capacity at any time.
10 The power switch button and oil-return button are designed independently to prevent incorrect operation.
11 Double LED lights cover the entire crimping area to ensure night work.
12 The tool can realize oil-return function without power by pressing the oil-return button, one button pressed to release pressure and return oil.
Warning: Do not rotate the tool head when there is pressure in the hydraulic circuit.
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
