High quality 12 Strand 6 80mm Orange Yellow UHMWPE Rope Uhmwpe Braided Synthetic Rope 12 Strand Mooring Rope Uhmwpe
- Category: >>>
- Supplier: Qingdao Boyuan Rope Co. Ltd.
Share on (1601175113236):
Product Overview
Description
Feature
Stronger: with a same diameter, their strength is comparable to that of wire rope. Lower elongation: their breaking elongation is close to that of wire rope.
Lighter: with a same strength, their weight(g/m) is only 1/8 of wire rope
Application: port towing, mooring system for ultra large container ships, Army&Navy equipment, offshore, aerospace, sport equipment, electrical communications, large precision object sling, etc. Material:UHMWPE
Structure:12 strand
Density: 0.97g/cm3
Melting point: 140℃
Elongation: 3.5%
Abrasion resistance: excellent
UV resistance: excellent
Chemical resistance: good
Dry and wet conditions: wet strength equals dry strength Non-rotating and anti-kinking, longer service life Easy to handle, inspect and repair
Lighter: with a same strength, their weight(g/m) is only 1/8 of wire rope
Application: port towing, mooring system for ultra large container ships, Army&Navy equipment, offshore, aerospace, sport equipment, electrical communications, large precision object sling, etc. Material:UHMWPE
Structure:12 strand
Density: 0.97g/cm3
Melting point: 140℃
Elongation: 3.5%
Abrasion resistance: excellent
UV resistance: excellent
Chemical resistance: good
Dry and wet conditions: wet strength equals dry strength Non-rotating and anti-kinking, longer service life Easy to handle, inspect and repair
Product Description
The mooring rope is made of UHMWPE Fibre,which has excellent UV resistance and oxidation resistance.According to he test result of the International maritime industry association test way,the breaking strength of this rope is 20 times more than wire rope,polyamide rope and polyester rope ,more than 30 times that of polypropylene rope.Special rope aftertreatment technology give the rope excellent corrosion resistance and abrasion resistance. It is widely used in the naval vessel,space flight and aviation,national defence equipment,ocean-going ships,oil platforms and many other fields.
Marine mooring
Marine or car towing
Heavy duty sling
high - altitude operations
protection
protection
♦ Abrasion resistant
♦ Easy to splice
♦ Excellent wear characteristics
♦ Extremely low stretch
♦ Flexible
♦ Floats
♦ High strength
♦ Easy to splice
♦ Excellent wear characteristics
♦ Extremely low stretch
♦ Flexible
♦ Floats
♦ High strength
♦ Highly flex-fatigue resistant
♦ Lightweight
♦ Maximum strength-to-weight ratio
♦ Similar elastic elongation to wire rope
♦ Torque-free construction
♦ Wire rope replacement
♦ Lightweight
♦ Maximum strength-to-weight ratio
♦ Similar elastic elongation to wire rope
♦ Torque-free construction
♦ Wire rope replacement
Technical Sheet
Uhmwpe Rope
Size | Weight | Unspliced Breaking Load | Spliced Break Load(LDBF) | ||||||||
Dia.mm | Cir.inch | g/m | kgs/220m | kN | ton | kN | ton | ||||
6 | 3/4 | 18 | 4 | 35 | 3.5 | 31 | 3.2 | ||||
8 | 1 | 34 | 8 | 64 | 6.6 | 58 | 5.9 | ||||
10 | 1-1/4 | 55 | 12 | 101 | 10.3 | 91 | 9.3 | ||||
12 | 1-1/2 | 83 | 18 | 150 | 15.3 | 135 | 13.8 | ||||
14 | 1-3/4 | 110 | 24 | 197 | 20.1 | 177 | 18.1 | ||||
16 | 2 | 130 | 29 | 230 | 23.5 | 207 | 21.1 | ||||
18 | 2-1/4 | 184 | 40 | 322 | 32.9 | 290 | 29.6 | ||||
20 | 2-1/2 | 227 | 50 | 384 | 39.2 | 346 | 35.3 | ||||
24 | 3 | 324 | 71 | 533 | 54.4 | 480 | 49.0 | ||||
28 | 3-1/2 | 444 | 98 | 704 | 71.9 | 634 | 64.7 | ||||
32 | 4 | 589 | 130 | 918 | 93.7 | 826 | 84.3 | ||||
36 | 4-1/2 | 720 | 158 | 1104 | 112.7 | 994 | 101.0 | ||||
40 | 5 | 880 | 194 | 1329 | 135.6 | 1196 | 122.0 | ||||
42 | 5-1/4 | 979 | 215 | 1459 | 148.9 | 1313 | 134.0 | ||||
44 | 5-1/2 | 1078 | 237 | 1589 | 162.1 | 1430 | 146.0 | ||||
46 | 5-3/4 | 1171 | 258 | 1698 | 173.2 | 1528 | 155.9 | ||||
48 | 6 | 1264 | 278 | 1807 | 184.4 | 1626 | 166.0 | ||||
50 | 6-1/4 | 1388 | 305 | 1971 | 201.1 | 1774 | 181.0 | ||||
52 | 6-1/2 | 1512 | 333 | 2136 | 217.9 | 1922 | 196.1 | ||||
54 | 6-3/4 | 1636 | 360 | 2300 | 234.7 | 2070 | 211.2 | ||||
56 | 7 | 1760 | 387 | 2464 | 251.5 | 2218 | 226.0 | ||||
58 | 7-1/4 | 1885 | 415 | 2622 | 267.6 | 2360 | 240.8 | ||||
60 | 7-1/2 | 2010 | 442 | 2778 | 283.4 | 2500 | 255.1 | ||||
62 | 7-3/4 | 2135 | 470 | 2936 | 299.5 | 2642 | 269.6 | ||||
64 | 8 | 2260 | 497 | 3092 | 315.5 | 2783 | 284.0 | ||||
66 | 8-1/4 | 2423 | 533 | 3293 | 336.1 | 2964 | 302.5 | ||||
68 | 8-1/2 | 2585 | 569 | 3496 | 356.7 | 3146 | 321.0 | ||||
70 | 8-3/4 | 2748 | 605 | 3697 | 377.2 | 3327 | 339.5 | ||||
72 | 9 | 2910 | 640 | 3898 | 397.7 | 3508 | 358.0 | ||||
74 | 9-1/4 | 3065 | 674 | 4080 | 416.3 | 3672 | 374.7 | ||||
76 | 9-1/2 | 3220 | 708 | 4263 | 435.0 | 3837 | 391.5 | ||||
78 | 9-3/4 | 3375 | 743 | 4444 | 453.5 | 4000 | 408.2 | ||||
80 | 10 | 3530 | 777 | 4628 | 472.2 | 4165 | 425.0 | ||||
Recommend Products
Applications
♦ ATV / Jeep Winch Lines
♦ Working Winch Lines
♦ Control Lines and Halyards
♦ Davits
♦ Emergency Tow Systems
♦ General Working Lines / Vessel Mooring
♦ Lifelines / lifting slings
♦ Primary Mooring Lines / Non-jacketed
♦ Working Winch Lines
♦ Control Lines and Halyards
♦ Davits
♦ Emergency Tow Systems
♦ General Working Lines / Vessel Mooring
♦ Lifelines / lifting slings
♦ Primary Mooring Lines / Non-jacketed
♦ Pulling / Stringing Lines
♦ Reef Lines
♦ Running Back
♦ Shield Hauler
♦ Stage, Event, and Special Effects Rigging
♦ Trapeze Line
♦ Trawl or Bridle Lines
♦ Tug Lines
♦ Robotics Projects
♦ Reef Lines
♦ Running Back
♦ Shield Hauler
♦ Stage, Event, and Special Effects Rigging
♦ Trapeze Line
♦ Trawl or Bridle Lines
♦ Tug Lines
♦ Robotics Projects
