JZB4112 High quality automatic feed drilling machine with Long service life and easy maintenance Automatic drilling machine

Share on (1601184309008):


Price:

Quantity:


Product Overview

Description



JZB4112 FOB To Shanghai Port Price:820.00USD
JZB4116 FOB To Shanghai Port Price:880.00USD
Specializing in manufacturing drilling machines for 60 years, there are about 200 drilling machine models with complete quality.The company has the right to run its own export business, and its sales network covers more than 20 provinces, cities and autonomous regions in China, and is exported to many countries in Europe, America, Southeast Asia and other places. "Quality first, customer first" is the company's business purpose, and "manufacturing quality drilling machines to continuously meet customer needs" is the company's eternal goal.




Products Description










Product Paramenters


MODEL
JZB4112
JZB4116
Max.Drilling capacity(mm)
12
16
Diameter of column(mm)
70
80
Max.spindle travel(mm)
Manual 100/automatic 90
Manual 100/automatic 90
Morse taper of spindle nose
B16
MT.2
Spindle speeds(r/min)
480-800-1400-2440-4100
260-400-460-950-1600-2100
Spindle feed range(mm/r)
0.05,0,08,0.20/3
0,08,0,10,0,14,0.20/4
Size of worktable(mm)
265*265
230*230
Size of base worktable(mm)
250*300
260*260
Distance from spindle axis to column surface(mm)
193
208.5
Distance from spindie nose to worktable(mm)
0-215
0-410
Distance trom spindle nose to base surface(mm)
205-460
576
Motor(kw)
0.55
0.75
G.W/N.W(kg)
140/115
140/115
Ship measurement(cm)
86*47.6*101.3
86*47.6*115


JZB4112
.JZB4116


MODEL
Max.Drilling capacity(mm)
20/16
25/20
20/16
25/20
Diameter of column(mm)
85
85
85
85
Max.spindle travel(mm)
Manual 110/automatic 90
Manual 110/automatic 90
Manual 110/automatic 90
Manual 110/automatic 90
Morse taper of spindle nose
MT.2
MT.3
MT.2
MT.3
Spindle speeds(r/min)
230-390-680-1230
230-390-680-1230
230-390-680-1230
230-390-680-1230
Spindle feed range(mm/min)
0-110 (stepless speed regulation)
0-110 (stepless speed regulation)
0-110 (stepless speed regulation)
0-110 (stepless speed regulation)
Size of worktable(mm)
-
-
290*320
290*320
Size of base worktable(mm)
335*335
335*335
335*335
335*335
Distance from spindle axis to column surface(mm)
242.5
242.5
242.5
242.5
Distance from spindie nose to worktable(mm)
-
-
0-380
0-380
Distance trom spindle nose to base surface(mm)
210-410
210-410
380-660
380-660
Motor(kw)
0.75 (6 poles)
1.1 (6 poles)
0.75 (6 poles)
1.1 (6 poles)
G.W/N.W(kg)
160/140
160/140
180/160
180/160
Ship measurement(cm)
86*52.6*89.3
86*52.6*89.3
86*52.6*112.3
86*52.6*112.3
L-With cooling system


JZB4020(L)/JZB4025(L)
JZB4120(L)/JZB4125(L)


MODEL
Max.Drilling capacity(mm)
31.5/25
31.5/25
31.5/25
31.5/25
Max.Tapping capacity(mm)
(M24/M20)
(M24/M20)
(M24/M20)
(M24/M20)
Diameter of column(mm)
100
100
100
100
Max.spindle travel(mm)
Manual 110/automatic 90
Manual 110/automatic 90
Manual 110/automatic 90
Manual 110/automatic 90
Morse taper of spindle nose
MT.3
MT.3
MT.3
MT.3
Spindle speeds(r/min)
140-220-320-370-460-550-1100-1170-1780
140-220-320-370-460-550-1100-1170-1780
140-220-320-370-460-550-1100-1170-1780
140-220-320-370-460-550-1100-1170-1780
Spindle feed range(mm/min)
0-110 (stepless speed regulation)
0-110 (stepless speed regulation)
0-110 (stepless speed regulation)
0-110 (stepless speed regulation)
Size of worktable(mm)
-
-
Ф320
Ф320
Size of base worktable(mm)
320*350
320*350
320*350
320*350
Distance from spindle axis to column surface(mm)
235
235
235
235
Distance from spindie nose to worktable(mm)
-
-
60-590
60-590
Distance trom spindle nose to base surface(mm)
350-700
350-700
1015
1015
Motor(kw)
1.1 (6 poles)
1.1 (6 poles)
1.1 (6 poles)
1.1 (6 poles)
G.W/N.W(kg)
260/225
260/225
330/280
330/280
Ship measurement(cm)
90*52.6*112.3
90*52.6*112.3
90*52.6*172.3
90*52.6*172.3
L-With cooling system
JZBSS032(L)/JZBS5032(L)  With tapping function


JZB4032(L)/JZBS4032(L)
JZB5032(L)/JZBS5032(L)


MODEL
ZB4040(L)(Gear Drive)
ZB5040(L)(Gear Drive)
Max.Drilling capacity(mm)
40/28
40/28
Diameter of column(mm)
115
115
Max.spindle travel(mm)
Manual 120/automatic 80
Manual 120/automatic 80
Morse taper of spindle nose
MT.4
MT.4
Spindle speeds(r/min)
95-170-280-540-960-1600
95-170-280-540-960-1600
Spindle feed range(mm/min)
0-103(stepless speed regulation)
0-103(stepless speed regulation)
Size of worktable(mm)
-
320*320(Ф320)
Size of base worktable(mm)
350*380
350*380
Distance from spindle axis to column surface(mm)
260
260
Distance from spindie nose to worktable(mm)
-
0-720
Distance trom spindle nose to base surface(mm)
90-580
765-1080
Motor(kw)
1.1
1.1
G.W/N.W(kg)
260/230
360/310
Ship measurement(cm)
78*67.8*121.4
78*67.8*171.4
L-With cooling system


ZB4040(L)(Gear Drive)
ZB4040(L)(Gear Drive)


MODEL
ZBS4040(L)(Gear Drive)
ZBS5040(L)(Gear Drive)
Max.Drilling capacity(mm)
40/28
40/28
Max.Tapping capacity(mm)
M30/M24
M30/M24
Diameter of column(mm)
115
115
Max.spindle travel(mm)
Manual 120/automatic 80
Manual 120/automatic 80
Morse taper of spindle nose
MT.4
MT.4
Spindle speeds(r/min)
95-170-280-540-960-1600
95-170-280-540-960-1600
Spindle feed range(mm/min)
0-103(stepless speed regulation)
0-103(stepless speed regulation)
Size of worktable(mm)
-
320*320(Ф320)
Size of base worktable(mm)
350*380
350*380
Distance from spindle axis to column surface(mm)
260
260
Distance from spindie nose to worktable(mm)
-
0-720
Distance trom spindle nose to base surface(mm)
90-580
765-1080
Motor(kw)
1.1
1.1
G.W/N.W(kg)
260/230
360/310
Ship measurement(cm)
78*67.8*121.4
78*67.8*171.4
L - With cooling system
ZBS4040(L)/ZBS5040(L) With tapping function


ZBS4040(L)(Gear Drive)
ZBS5040(L)(Gear Drive)


MODEL
Z4032B
Z5032B
Max.Drilling capacity(mm)
31.5/25
31.5/25
Max.Tapping capacity(mm)
M22
M22
Diameter of column(mm)
120
120
Max.spindle travel(mm)
Manual 160/automatic 140
Manual 160/automatic 140
Morse taper of spindle nose
MT.4
MT.4
Spindle speeds(r/min)
125-205-250-360-410-535-715-865-1070-1520-1720-3030
125-205-250-360-410-535-715-865-1070-1520-1720-3030
Spindle feed range(mm/min)
0.10 0.20 0.30/3
0.10 0.20 0.30/3
Size of worktable(mm)
-
500*420
Size of base worktable(mm)
350*380
350*380
Distance from spindle axis to column surface(mm)
300
300
Distance from spindie nose to worktable(mm)
-
0-730
Distance trom spindle nose to base surface(mm)
150-620
970-1260
Motor(kw)
1/1.2(Two speed)
1/1.2(Two speed)
G.W/N.W(kg)
460/420
550/500
Ship measurement(cm)
105*62.6*125.3
105*62.6*205.3


Z4032B
Z5032B


MODEL
ZB4050(S)
ZB4050A(S)
ZB5050(S)
Max.Drilling capacity(mm)
50/45
50/45
50/45
Max.Tapping capacity(mm)
M30
M30
M30
Diameter of column(mm)
140

140
Max.spindle travel(mm)
Manual 150/automatic 120
Manual 150/automatic 120
Manual 150/automatic 120
Morse taper of spindle nose
MT.4
MT.4
MT.4
Spindle speeds(r/min)
70-150-260-370-825-1430 (45-100-170-245-550-950)
70-150-260-370-825-1430 (45-100-170-245-550-950)
70-150-260-370-825-1430 (45-100-170-245-550-950)
Spindle feed range(mm/min)
0-125(stepless speed regulation)
0-125(stepless speed regulation)
0-125(stepless speed regulation)
Size of worktable(mm)
-
-
540*440
Size of base worktable(mm)
415*400
500*450
415*440
Distance from spindle axis to column surface(mm)
315
325
315
Distance from spindie nose to worktable(mm)
-
-
0-607
Distance trom spindle nose to base surface(mm)
135-685
220-670
912-1200
Motor(kw)
2.2(2.2/1.5)
2.2(2.2/1.5)
2.2(2.2/1.5)
G.W/N.W(kg)
500/425
650/540
700/600
Ship measurement(cm)
110*72.6*141.3
120*72.6*155.3
110*72.6*201.3
S-Two-speed motor


ZB4050(S)
ZB4050A(S)
ZB5050(S)


Company Profile


Is a domestic enterprise specializing in the production of drilling machine series products. It is the director unit of cmtba Drilling and Boring Machine Branch, and the member unit of Drilling and Boring Machine Industry Standardization Technical Committee.
The company has nearly 120 employees, including 40 engineers and technicians, and has more than 200 sets of general-purpose mechanical processing and inspection equipment. The main products produced by the company are: desktop drilling machine, vertical drilling machine, milling drilling machine, tapping machine, dual-purpose drilling and tapping machine, radial drilling machine, universal tool grinder, numerical control drilling machine, numerical control milling machine, vertical machining center, deep hole drill, axial press and so on. With an annual output of more than 20,000 series drilling machines, we can design and customize all kinds of precise, efficient and special machine tools according to users' needs, and provide integrated drilling and processing solutions. The company has always paid attention to product quality and the development of new products, always adhered to the production concept of "innovation and refinement, pursuit of perfection", constantly introduced and absorbed advanced technology and equipment, and actively explored modern management mode. The company has passed the ISO 9001:2008 international quality management system certification.










Product packaging










FAQ


1. Who are we?
A:Wuxi Mingxu Machinery Equipment Co., Ltd. was restructured from Wuxi Machinery Equipment Co., Ltd. Mainly produces and sells mechanical equipment, forging equipment, grinders, machining centers, hot die forging equipment, CNC machine tools, lathes, milling machines, machine tool parts and so on.

2.What is the package of the machines?
A: The machines standard packed by iron pallets with steel box ,high quality package to reduce the risk of damage during delivery.

3.What is your MOQ of this item?
A: Our MOQ is one set.

4.How can I choose the most suitable machines ?
A: Please let us know your machining demand or machine size ,we can choose the best model for you , or you can choose the exact model by yourself. You can also send us the products drawing ,we will choose the most suitable machines for you .

5.When is the delivery time?
A: Conventional Machines, we will deliver then within 20 working days after receiving your deposit. If some special machines will be longer, please contact us for details. According to the delivery date at that time, we will give you a reply accordingly.

6. What is the payment Terms ?
A : Alibaba or T/T ,30% initial payment when order ,70% balance payment before shipment ;

7.What kind of trade terms can you do ?
A:EXW,FOB,CFR,CIF,Etc.

8.What is Trade Assurance?
A:Trade Assurance is a free service by Alibaba .com that's designed to help create trust between buyers
and suppliers.Trade Assurance helps buyers in the event of shipping and quality-related dispute.

9.Dose Trade Assurance charge fees?
A: No.Trade Assurance is free for both buyers and suppliers.
