Price:$29,000.00

Quantity:


Product Overview

Description



Product description


What advantages can we bring to you:
(1)Jiaqing factory has advanced research and development means, perfect development materials, reasonable engineering and assembly tools, smooth product assembly lines, perfect quality assurance system and the highest performance cost in the world.
(2): For consumers, our products are affordable and have a long service life. The product model can meet your needs and support customization
(3): For suppliers, we provide you with sufficient profit margins. We provide you with testing to ensure the quality of the product before leaving the factory. At the same time, we support customized colors and product brands


Product Paramenters


Jiaqing Heavy Industry's self-made 6T configuration table
Brand
JQDC
Rotary mechanism
Secondary planetary
steering
Chassis Model
Made by the manufacturer
Outrigger
5 fully hydraulic
outriggers
total mass
7100KG
Outrigger span (transverse)
4950mm
Full crane size
6100*1950*2600mm
Outrigger span (longitudinal)
3800mm
wheelbase
2100mm
Protective devices
two-way hydraulic lock
Maximum rated lifting
capacity
6000kg
Work lights
two
maximum lifting height
21m
hydraulic pump
single pump
engine model
4102motor
Dual use of oil and electricity
11KW-6 pole copper core motor
power
64KW
Rotation radius
1.7m
horsepower
90 horsepower
Frame size
300mm*150mm
gearbox model
Wanliyang gearbox (high
and low speed)
top of posterior displacement
standard configuration
tire
750-16
Lifting operation mode
Pushrod operation
brake system
Air brake（ABS）
Rod output form
Synchronous scaling
Steering mechanism
Hydraulic directional
assistance
Type of boom structure
4m * 7 section arm
Main lifting mechanism
8 ton winch
Big arm size
500mm*300mm
Slewing bearing
1.05 meter turntable
Optional configuration: upper air conditioning, lower air conditioning, weighing device, torque limiter, wireless camera, hanging
basket, air cushion seat
Product features: Equipped with a central rotator, the turntable can rotate 360 degrees at will. Equipped with a planetary
reduction mechanism, the rotation is faster and smoother. Equipped with a hydraulic heat dissipation system to reduce oil
temperature and improve efficiency; The driving is equipped with high and low speeds, steering wheel assistance, and air brake,
making driving the vehicle easier and more flexible.


Company Profile


Jining Jiaqing Special Vehicle (Group) Co., Ltd, a modern corporate enterprise, established in 2012,registered capital 22,000,000 RMB, professionally producing truck crane series , self-made crane series, truck mounted crane series,located in Changgou Industrial Park, Jining City, Shandong Province, covering 80232 square meters. Now our company owns fixed assets 23000000 RMB,196 employees, 40 professional engineers , 8 senior engineers , 16 senior technicians. Acquired ISO 9001:2015 national quality management system certification and the ISO13485:2016 national quality management system certification, passed the European Community CE quality certification.11 years experience and nearly 1000 sets annual sale of cranes make us one of the biggest crane manufacturer in China. Our company has many years of production experience and can produce according to customer needs, support customized orders and process according to drawings.Welcome to visit our factory when come to China,more information and pictures will be sent after getting your reply.
333


More details


Enlarged and thickened wear-resistant turntable
Bold and heavy hydraulic support outriggers
380V motor 15 kW
