Last price FAW J6P J5P 6x4 crane truck mounted 12 tons

Name: Last price FAW J6P J5P 6x4 crane truck mounted 12 tons
SKU: 1601193196663
Price: $30,300.00 USD
Availability: InStock

Price:$30,300.00

Quantity:

Product Description

FAW 6x4 cargo truck with 12 tons crane
Engine
Engine model	WP10.270E32
Emission standards	EURO 3
Engine type	Diesel engine
Engine displacement (L)	9.726
Rated power of engine (kw/hps)	199
Maximum torque (N.m/rpm)	700/1500
Gearbox
Gearbox model	Manual 9JS119T
Rear axle
Rear axle model/load (T)	double10T
Rear axle speed ratio	5.428
Cabin type	Left side driving, flat head,one row with sleeping bed, electric window
Drive form	6x4
Tire type/number	11.00R20/10+1 pcs
Weight parameter
Curb weight (Kg)	12155
Rated load capacity (Kg)	20000
Performance parameter
Maximum speed (km/h)	95
Minimum ground clearance (mm)	300
Dimension parameters
Overall dimensions (LxWxH)mm	11900x2500x3800
Cargo box dimension(mm)	8500x2300x800
Wheelbase(mm)	5700+1350
Rated voltage (V)	24

Model	SQS300-4
Max lifting capacity(kg)	12000
Max.outreach	15.8
Max. lifting height	17.8
Rated Flow of Hydraulic System L/min	63
Oil tank capacity	200
Rated Pressure of Hydraulic System	26
Recommend Power	52
Installation space	980
Slewing angle	360°
Crane Weight	5600
Boom section	octangle
Leg structure	Double cavity telescopic square leg

Packing & Delivery

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.

New products from manufacturers at wholesale prices
