Non woven Melt Blown Extruder metering pump manufacturer 30cc RT hot melt glue adhesive gear metering pump
Non-woven Melt Blown Extruder metering pump manufacturer 30cc RT hot melt glue adhesive gear metering pump

Non woven Melt Blown Extruder metering pump manufacturer 30cc RT hot melt glue adhesive gear metering pump

Share on (1601193389666):


Price:

Quantity:


Product Overview

Description





Feature
1. No pulse accurate delivery
Through the gears to provide continuous accurate fluid transportation. with servo motor and stepper motor delivery accuracy of +/-0.5%.
2. Strong vacuum suction capacity
High conveying pressure and smooth Operation High pressure delivery in low viscosity liquids.
3. No leakage
Magnetic drive and static O-ring seal can ensure that the medium in the pump is isolated from the outside world to achieve no leakage.
4.Long Lifespan
 Top-tier materials and precision technology, advanced techniques to prolong its operational lifespan.


Product Name
Gear Metering Pump
Material
Stainles Steel/Tool Steel/9CR18
Medium
Low viscosity fluid
Medium viscosity range
0-3000cps
Flow capacity
0.05CC/R-200CC/R
Min inlet pressure
 <0.05Mpa
Max Outlet pressure
 <30Mpa(Can Oem)
Working speed
 5~200r/min
Process temperature
 -30℃-200℃
Working noise
4000rpm<60dB




Application
1. Polymer extrusion molding, such as granulation, film, pipe, plate, sheet, etc.
2. Transporting high-viscosity materials such as PC, PMMA, ABS, HIPS, PET, PVB, PS, PP, PA, PE, PVA and so on.
3. Simultaneously, transporting rubber, asphalt, paint, adhesives, coatings, lubricants, Polyalcohol and other non-particulate
impurities.
4. Pressurized transporting and spinning polyester for cotton-fiber, polypropylene and other chemical fiber melt.


Product Description




Parameters


 High Performance Epoxy Resin Glue Injection Hot Melt Gear Pump

  The design utilizes high standard external spur gears enclosed within a close tolerance housing assembly. This provides you the precise volume of fluid dispensed per shaft revolution. The housing is constructed from a precision ground and lapped three-plate assembly. This assembly is aligned with dowels to allow close control of operating clearances. This construction method in combination with several proprietary internal features is what ensures precise, pulseless and reliable flow under varying process conditions.



Model
Displament
Total
Height
Base
Height
Min
Pressure
Max
Pressure
Accuracy
Temperature
GWMP-0.15
0.15
83
28.1
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-0.3
0.3
85
30.2
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-0.6
0.6
85
32
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-1.2
1.2
90
34
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-2.4
2.4
100
42
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-3.6
3.6
105
50
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-6
6
130
41
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-9
9
135
46
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-12
12
140
51
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-15
15
145
56
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-20
20
150
64
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-30
30
165
80
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-40
40
90
215
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-50
50
97
215
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-60
60
104.5
230
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-75
75
112
230
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-80
80
Customized
Customized
<0.2Mpa
<30Mpa
+/-3%
200℃
GWMP-125
125
Customized
Customized
<0.2Mpa
<30Mpa
+/-3%
200℃




Note:Direction of rotation: clockwise from the axis of rotation




Model
0.15cc
0.3cc
0.6cc
1.2cc
2.4cc
3.2cc
3.6cc
A
83
85
85
90
100
103
105
B
28.1
30.2
32
34
42
47.6
50


Model
6cc
9cc
12cc
15cc
20cc
25cc
30cc
A
130
135
140
145
150
158
165
B
41
46
51
56
64
72
80


Company info
1. High-tech enterprise, with a number of national invention patents
2. Integrates research and development, production, processing and sales, and has independent import and export rights 3.13 years of experience in instrument production and sales
4. Wide range of products, covering flow, liquid level, gear pump, temperature, pressure instrument , etc.
5. A number of metering equipment experts and senior engineers with high technical level
6. Products have been sold to more than 100 countries and involved in more than 100 industries.
7. English sales team, Russian sales team, domestic sales team.
8. Provide complete set of system solutions.






Company Profile




















FAQ


Q1: Are you a manufacturer or a trading company?
A: We are a manufacturer specializing in the production of Flow Meter, Metering Pumps, Level Meter and other types of pumps and Flow Meter, as well as pump-related products. Our products have passed the test.
Q2.Why choose us?
A:We have more than 36 years of experience in the pump and flowmeter product industry. High-quality products and competitive prices. We have professional business personnel and engineers to provide you with selection assistance and technical support.
Q3: What is the minimum order quantity for your products?
A: Different models have different MOQs, please check with the salesperson.
Q4: How long is your delivery time?
A: The samples can be sent to you within 3-15 days. Bulk orders can be shipped to you within 10-15 days after the order is confirmed.
Q5:How to pay?
A:We accept Paypal, Western Union, T/T, cAlipay, Ali Assurance Order Payment, Webmoney ,USD Bank Account ect.
Q6:Can you offer OEM and ODM?
Yes,we can provide OEM and ODM service to meet any of your needs
Q7:What is your terms of payment?
A:T/T, Full payment before shipment
