Low Price Gasoline Diesel Emergency Ambulance Vehicle Rescue Car Hospital Disability Transfer Ambulance

Main specification

G.V.W(kg)

3510

Dimensions (length × width × height)(mm)

5341X2032X2460,2590

Curb weight(kg)

2560

Front suspension/rear suspension (mm)

1014/1207,1014/1027

Number of occupants

5-7

Approach Angle/departure Angle (°)

20/25

Axle number

1570/1940

Max speed(KM/h)

156

Remark:

Remarks: The car is equipped with special devices such as medical equipment cabinets, oxygen cylinders, stretchers, disinfection lights, sign lights and alarms. Optional side sliding door pedal according to the chassis.

Optional I-shaped sign light or special-shaped warning light. Vehicle height at the forehead position (mm): 2460; optional I-shaped sign light at the roof position (mm): 2590; optional roof decorative tail wing height ( mm): 2470, optional tail door boarding pedal length (mm): 5521,

Optional one or more flashing warning lights around the roof, ABS system controller model: EV5051

 Chassis specification

Chassis model

JX6533P-L5

Wheelbase(mm)

 3300

Axle number

2

Tire number

4

Tire size

215/75R16LT

Number of leaf springs

-/1,-/2

Front track (mm)

1736

Fuel type

diesel

Rear track (mm)

1720

Emission Standards

Euro V

 Engine model

Engine manufacturer

Displacement (ml)

Power(KW)

DURATORQ4D206H

Jiangling Motors Corporation, Ltd

1998

90
