Quality Piston Air Compressor Pump Heads Natural Gas Station Dental Air Compressor
- Category: >>>
- Supplier: Bengbu Aot Compressor Co. Ltd.
Share on (1601193663785):
Product Overview
Description
Product Description
Product overview:
1. Product overview The methane compressor is a large, medium and small methane compressor developed by our company in response to the national demand for new and renewable energy. Our biogas compressor has a unique professional technical level, high cost performance, and the exhaust pressure ranges from 0 2MPa to 25 MPa. The exhaust volume ranges from 0 From 2m3/m in to 40m3/min, compressors are available in Z type, D type and other forms
2. Features and performance: the whole machine is characterized by low noise, high stability, simple structure and convenient maintenance. The product is safe and reliable
1. Product overview The methane compressor is a large, medium and small methane compressor developed by our company in response to the national demand for new and renewable energy. Our biogas compressor has a unique professional technical level, high cost performance, and the exhaust pressure ranges from 0 2MPa to 25 MPa. The exhaust volume ranges from 0 From 2m3/m in to 40m3/min, compressors are available in Z type, D type and other forms
2. Features and performance: the whole machine is characterized by low noise, high stability, simple structure and convenient maintenance. The product is safe and reliable
Characteristics of performance
skid-mounted body | Compact structure, beautiful appearance, small floor area, easy lifting and maintenance. |
Unit | Large air volume, high reliability of working performance, stable operation, low vibration noise. |
Cooling System | The high efficiency air cooler is used as the cooling system to save resources, improve efficiency, and make the cooling system simple in structure and convenient in disassembly. |
Priority control panel | The control air source is provided by the high-pressure bottle group, with high safety, stable control and three-line efficient and fast charging function. |
Automatic control | Unattended automatic control can realize automatic switching of two working conditions. |
Driver | The motor USES frequency conversion soft start, the connection USES the high elastic coupling direct connection |
Detailed Images
Features:
The whole machine has the characteristics of safety and reliability, high stability, complete configuration and convenient maintenance
Technical Parameters
Compressor | Product Model | ZW-2.0/1-25 | |||
Type | Z Type | ||||
Compressed medium | Methane gas | ||||
Nominal volume flow(Nm/min) | 3.5 | ||||
Compression stage | 3 | ||||
Cylinder number | 3 | ||||
Driving mode | Belt | ||||
Noise (sound pressure level) dB(A) | ≤85 | ||||
Cooling mode | Air cooling | ||||
Rotational speed (r/min) | 550★ | ||||
Suction pressure(mpa g) | 0.1 | ||||
Discharge Pressure(Mpa g) | 2.5 | ||||
Suction temperature (℃) | ≤40 | ||||
Discharge temperature (℃) | ≤160, (After cooling≤ambient temp+10℃) | ||||
Lubrication type | Crankshaft, connecting rod, cross head | Oil lubrication | |||
Cylinder, Packing | Oil-free lubrication | ||||
Motor | Model | YBX3-225S-4 | |||
Explosion-proof grade | DIIBT4 | ||||
Rotational speed (r/min) | 1480★ | ||||
Rated voltage (V) | 220 | ||||
Rated frequency(Hz) | 50 | ||||
Rated current (A) | 121.38 | ||||
Rated power (KW) | 37 | ||||
Compressor size (L×W×H) mm | ≈2800×1600×1600★ | ||||
Weight(kg) | ≈2500★ | ||||
Scope of supply
No. | Name | Number |
1 | Compressor host | 1 |
2 | Explosion-proof motor | 1 |
3 | Gas-liquid separator | 1 |
4 | Shared chassis | 1 |
5 | The relief valve | 1 |
6 | Belt | 1 set |
7 | Piping components | 1 set |
8 | Random spare parts | 1 set |
9 | The technical documentation | 1 set |
10 | Non explosion proof control cabinet | High inlet pressure automatic alarm shutdown Low inlet pressure automatic alarm shutdown |
Our Company
Certifications
Why Choose Us
Packing & Delivery
FAQ
Q1: Why choose us?
A: Bengbu AOT Compressor Co., Ltd., is specialized in Special Gas Compressor. We warmly welcome your small trial order for quality or market test.
Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Anhui, China. Both OEM & ODM service can be accepted.
Q3: What's your delivery time?
A: Generally 30 to 60 days, if urgently order, please contact our sales in advance.
Q4: How long is your air compressor warranty?
A: One year for the whole machine and two years for screw air end, except spare parts.
Q5: How long could your air compressor be used?
A: Generally, more than 15 years.
Q6: What's payment term?
A: T/T, L/C, Western Union, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q7: How about your customer service?
A: 24 hours online service available. 48hours problem solved promise.
A: Bengbu AOT Compressor Co., Ltd., is specialized in Special Gas Compressor. We warmly welcome your small trial order for quality or market test.
Q2: Are you a manufacturer or trading company?
A: We are professional manufacturer with big modern factory in Anhui, China. Both OEM & ODM service can be accepted.
Q3: What's your delivery time?
A: Generally 30 to 60 days, if urgently order, please contact our sales in advance.
Q4: How long is your air compressor warranty?
A: One year for the whole machine and two years for screw air end, except spare parts.
Q5: How long could your air compressor be used?
A: Generally, more than 15 years.
Q6: What's payment term?
A: T/T, L/C, Western Union, Credit Card, and etc. Also we could accept USD, RMB, Euro and other currency.
Q7: How about your customer service?
A: 24 hours online service available. 48hours problem solved promise.
Q8: How about your after-sales service?
A: Installation Services and online instructions. Well-trained engineers available to overseas service.
A: Installation Services and online instructions. Well-trained engineers available to overseas service.
