Waterproof P4 P5 P6 P8 P10 Outdoor 3d Outdoor Pantalla LED Display Screens Panel For Outdoor Advertising Sign
- Category: >>>
- Supplier: Shenzhen Royal Display Technology Co. Ltd.
Share on (1601194436065):
Product Overview
Description
Product Description
Model | P2.5 | P3 | P3.076 | P4 | P5 | ||||
Pixel Pitch(mm) | 2.5 | 3 | 3.076 | 4 | 5 | ||||
Pixel Matrix Per Sq.m | 160000 | 111111 | 105625 | 62500 | 40000 | ||||
Pixel Configuration | SMD1415 | SMD1415 | SMD1415 | SMD1921 | SMD1921 | ||||
Brightness (nits) | 5000 | 5000 | 5000 | 5000 | 5500 | ||||
Scan | 16S | 16S | 13S | 10S | 8S | ||||
Module Dimension | 320mm*160mm | 192mmx192mm | 320mmx160mm | 320mmx160mm | 320mmx160mm | ||||
Cabinet Weight | 46kg / 101lb (Iron) | 46kg / 101lb (Iron) | 45kg / 99lb (Iron) | 44kg / 97lb (Iron) | 43kg / 95lb (Iron) | ||||
Power Con. (Max / Avg) | 900/ 180 w/sq.m | ||||||||
Cabinet Dimension | 960x960mm （Cabinet size can be changed according to module size） | ||||||||
IP Rate | IP65 | ||||||||
Service Access | Rear | ||||||||
Refresh Rate (HZ) | >1920 | ||||||||
Grey Scale (bit) | 16bit | ||||||||
Viewing Angle (H/V) | 140/140 | ||||||||
Input Voltage (AC) | 110V/240V | ||||||||
Model | P6 | P6.67 | P8 | P10-4S | P10-2S | ||||
Pixel Pitch(mm) | 6 | 6.67 | 8 | 10 | 10 | ||||
Pixel Matrix Per Sq.m | 27777 | 22477 | 15625 | 10000 | 10000 | ||||
Pixel Configuration | SMD2727 | SMD3535 | SMD3535 | SMD3535 | SMD3535 | ||||
Brightness (nits) | 5000 | 5500 | 5000 | 5000 | 6000 | ||||
Scan | 8S | 8S | 5S | 4S | 2S | ||||
Module Dimension | 192mmx192mm | 320mmx160mm | 320mmx160mm | 320mmx160mm | 320mmx160mm | ||||
Cabinet Weight | 42kg / 93lb (Iron) | 42kg / 93lb (Iron) | 41kg / 90lb (Iron) | 40kg / 88lb (Iron) | 40kg / 88lb (Iron) | ||||
Power Con. (Max / Avg) | 900/ 180 w/sq.m | ||||||||
Cabinet Dimension | 960x960mm （Cabinet size can be changed according to module size） | ||||||||
IP Rate | IP65 | ||||||||
Service Access | Rear | ||||||||
Refresh Rate (HZ) | >1920 | ||||||||
Grey Scale (bit) | 16bit | ||||||||
Viewing Angle (H/V) | 140/140 | ||||||||
Input Voltage (AC) | 110V/240V | ||||||||
Product packaging
Company Profile
FAQ
Q1.Can I have a sample order for the LED display?
A:Yes,we welcome sample orders to test and check quality.Both for the module or the whole screen.
Q2.What about the lead time?
A:Order less than 100 square meters lead time to take 15 working days
Q3.Do you have any MOQ limit for LED display orders?
A:Low MOQ,1 square meter or a module checking is available
Q4.How do you ship the goods and how long does it take to arrive?
A:We mostly accept FOB train terms,but we can help you order and arrange a shipping agent.It usually takes 20 30 days on the sea.a few days for customs clearance
Q5.How to proceed with an order for an LED display?
A:Firstly let us know your requirements or application.
Secondly,We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places a deposit for the formal order.
Fourthly We arrange the production.
Q6.Is it OK to print my logo on the products?
A:Yes.Please inform us formally before our production and confirm the design firstly based on our sample.
Q7:Do you offer a guarantee for the products?
A:Yes,we offer 1-5 years warranty for our products.
A:Yes,we welcome sample orders to test and check quality.Both for the module or the whole screen.
Q2.What about the lead time?
A:Order less than 100 square meters lead time to take 15 working days
Q3.Do you have any MOQ limit for LED display orders?
A:Low MOQ,1 square meter or a module checking is available
Q4.How do you ship the goods and how long does it take to arrive?
A:We mostly accept FOB train terms,but we can help you order and arrange a shipping agent.It usually takes 20 30 days on the sea.a few days for customs clearance
Q5.How to proceed with an order for an LED display?
A:Firstly let us know your requirements or application.
Secondly,We quote according to your requirements or our suggestions.
Thirdly customer confirms the design document and places a deposit for the formal order.
Fourthly We arrange the production.
Q6.Is it OK to print my logo on the products?
A:Yes.Please inform us formally before our production and confirm the design firstly based on our sample.
Q7:Do you offer a guarantee for the products?
A:Yes,we offer 1-5 years warranty for our products.
