Vehicles Mobile DVR 4CH 4G WIFI And GPS 1080P MDVR Bus Taxi Truck MDVR Video Recorder
- Category: >>>
- Supplier: Shenzhen Daovay Technology Co. Ltd.
Share on (1601194592997):
Product Overview
Description
Vehicles Mobile DVR 4CH 4G WIFI And GPS 1080P MDVR Bus Taxi Truck MDVR Video Recorder
Customer Feedback
Product Description
VL-MD4 integrates in car video monitoring, driving recorder, ADAS advanced driving assistance system, and DSM driver status Integrate analysis system and BSD blind spot monitoring. Built in AI high-performance processing chip, using H.265 video encoding and decoding technology, Implemented simulation of high-definition video recording, storage, and playback. By combining 3G/4G wireless transmission technology and positioning technology, it is possible to achieve
Real time uploading of video recordings, car driving records, analysis of driving behavior, and uploading of alarm evidence. By controlling The center can remotely monitor, analyze, and process vehicles in real-time.
Real time uploading of video recordings, car driving records, analysis of driving behavior, and uploading of alarm evidence. By controlling The center can remotely monitor, analyze, and process vehicles in real-time.
Product Paramenters
Main Features:
1. Intelligent single-chip design, supporting ADAS, DSM, BSD
2. H.265 encoding, high compression ratio, clear images, and saves memory space
3. Supports 4-way 1080P/720P AHD, real-time video preview and storage
4. AHD/TVI/CVI/IPC/Analog five video inputs
5. Built in G-Sensor for real-time monitoring of vehicle driving behavior
6. Support reverse image distance measurement assistance
7. Support image horizontal and vertical mirror adjustment
8. Widely used for buses, trucks, trailers, goods, vans, vehicles, taxis...
2. H.265 encoding, high compression ratio, clear images, and saves memory space
3. Supports 4-way 1080P/720P AHD, real-time video preview and storage
4. AHD/TVI/CVI/IPC/Analog five video inputs
5. Built in G-Sensor for real-time monitoring of vehicle driving behavior
6. Support reverse image distance measurement assistance
7. Support image horizontal and vertical mirror adjustment
8. Widely used for buses, trucks, trailers, goods, vans, vehicles, taxis...
project | Equipment parameters | performance index |
system | operating system | Embedded Linux operating system |
Operational language | Chinese/English | |
Operation interface | Graphical menu operation interface, supporting mouse operation | |
Audio and video | Video input | 4-way 1080P AHD/TVI/CVI/CVBS |
Video output | VGA+CVBS | |
Audio input | 4-way | |
Audio output | 2 analog outputs (2W) | |
Video format | PAL/NTSC | |
video compression | H.264/H.265 | |
Recording resolution | 1080P/720P/960H/D1/CIF | |
Recording quality | Available for levels 1 to 6 | |
Audio Format | G.711A G.711U G.726 | |
Video recording and playback | storage medium | SD card |
Audio bit rate | 8Kb/s | |
Video query | Retrieve by channel and recording type | |
Replay Theater | Local multiplexing | |
Local backup | Supports SD cards and USB drives | |
Upgrade mode | Manual upgrade, automatic upgrade, remote upgrade | |
Upgrade method | USB drive, SD card, network upgrade | |
Software upgrade | Audio and video input | 4-way M12 aviation head interface |
Audio and video output | 1 VGA video output, 1 M12 aviation audio and video output | |
Physical interface | Alarm input | 4 inputs (positive/negative triggering can be configured, 1 and 2 supports analog inputs) |
Alarm output | Supports 2 open drain outputs and can drive relays (<150mA) | |
Vehicle speed pulse | 1 unit | |
RS232 | 2 RS232 interfaces | |
MIC/SPK | 4PIN MIC/SPK | |
RS485 | 1 RS485 interface | |
Other interfaces | LED indicator light | PWR/RUN/SD/ALM |
IPC | 6Pin M-12 Aviation Head | |
SD card interface | 1 SD card interface supports a maximum of 512G (can be expanded by 1 additional SD) | |
Disk lock | 1 unit | |
Wireless interface | GNSS module | GPS/BD/GLONASS |
Wifi | WIFI module, frequency 2.4GHz | |
3G/4G | 4G module, 4G full network connectivity | |
Active safety interface | ADAS interface | 1 ADAS, 1080P/720P |
DSM interface | 1 channel DSM, 1080P/720P | |
BSD interface | 1-way BSD, 1080P/720P | |
other | Power input | DC：9V~36V |
storage capacity | 1080P 622MB/hour/channel H.265 | |
1080P 1.2G/hour/channel H.264 | ||
Typical power consumption | Operating power consumption: AVG 4.8W (excluding peripherals) | |
Static power consumption: 12V@2.4mA | ||
Load capacity | Camera+screen: 12V@1.5mA | |
IPC: 12V@750mA | ||
Host power consumption: 12V@mA | ||
Power output | 5V@500mA | |
Dimensions (length x width x height) | 187mm * 154.9mm * 55.55mm |
Product Functions
Application Scenario
Company Profile
Shenzhen daovay Technology Co.,Ltd. is a one-stop industrial IoT solution operation service provider. It takes "location" and"temperature" IoT applications as its product business direction, provides integrated software and hardware development and delivery services, and creates a stable and mature IoT-PaaS platform. The current business involves fleet operation, asset management, cargo tracking, food cold chain, IoT platform and other industry sectors. It has established two operation centers in Shenzhen and Xi'an, China. It has also ventured into international business. It has established co-operating companies in Africa and Southeast Asia, occupying an important position in the industry in the local market. In addition to the characteristics of personalized customization and technical development services in place, more importantly, we position ourselves as a "system
integrator" at the technical level of our products. As a one-stop industrial IoT solution operator and service provider, it needs to have strong and flexible integration and integration capabilities. Based on IoT applications such as "location" and"temperature", it builds the digital infrastructure of the industries it serves.
integrator" at the technical level of our products. As a one-stop industrial IoT solution operator and service provider, it needs to have strong and flexible integration and integration capabilities. Based on IoT applications such as "location" and"temperature", it builds the digital infrastructure of the industries it serves.
Packing
FAQ
Q1. Are you a manufacturer?
Yes, we are a manufacturer of GPS trackers in China
Q2. What is your sample policy?
We can provide samples, but customers have to pay the sample fee and courier fee, sorry for this
Q3. How is your delivery time?
The exact delivery time depends on the item and quantity you ordered.
Q4. Can you provide GPS tracking system and APP?
Yes, we have our GPS tracking software/system and APP. We also offer protocols for integration into your system.
Q5: Does the GPS tracker need a SIM card?
1. It depends on the model. Most of our GPS tracking devices require a SIM card, please communicate with our product manager indetail before ordering.
2. Generally, 4G devices are compatible with 3G and 2G networks, so a 4G SIM card is required. 2G/3G SIM cards cannot be used on 4G devices.NB-IOT devices require NB-IOT network, please confirm with your operator whether your area is covered by stable NB-IOTnetwork.
3. We can also customize e-SIM solutions. Please feel free to contact us if needed.
Q6: What is the shipping method?
It can be shipped by sea, air or express (EMS, UPS, DHL, TNT, FEDEX, etc.). Please confirm with us before placing an order.
Q7: How about quality control and warranty?
All products go through strict quality inspection before packing.
Yes, we are a manufacturer of GPS trackers in China
Q2. What is your sample policy?
We can provide samples, but customers have to pay the sample fee and courier fee, sorry for this
Q3. How is your delivery time?
The exact delivery time depends on the item and quantity you ordered.
Q4. Can you provide GPS tracking system and APP?
Yes, we have our GPS tracking software/system and APP. We also offer protocols for integration into your system.
Q5: Does the GPS tracker need a SIM card?
1. It depends on the model. Most of our GPS tracking devices require a SIM card, please communicate with our product manager indetail before ordering.
2. Generally, 4G devices are compatible with 3G and 2G networks, so a 4G SIM card is required. 2G/3G SIM cards cannot be used on 4G devices.NB-IOT devices require NB-IOT network, please confirm with your operator whether your area is covered by stable NB-IOTnetwork.
3. We can also customize e-SIM solutions. Please feel free to contact us if needed.
Q6: What is the shipping method?
It can be shipped by sea, air or express (EMS, UPS, DHL, TNT, FEDEX, etc.). Please confirm with us before placing an order.
Q7: How about quality control and warranty?
All products go through strict quality inspection before packing.
