HaiLin 4 Pipe FCU Thermostat 220V On/Off Valve Temperature Controller OEM
- Category: >>>
- Supplier: Beijing HaiLin Control Technology Inc.
Share on (1601195452095):
Product Overview
Description
VR
Product Name | Versatile D Series FCU Thermostat | ||||||
Model | HL2023FCV2-L | ||||||
Power Supply | AC85～250V, 50/60Hz | ||||||
Display Temp.Resolution | 0.5℃ | ||||||
Operating Temperature Range | 0~55℃ | ||||||
Operating Humidity Range | 5-95%RH (No Condensation) | ||||||
Power Consumption | ＜2 W | ||||||
Terminations | One 2.5mm² Or Two 1.5mm² Wires | ||||||
Max Load Current | ＜ 2A (Resistive),＜ 1A (Inductive) | ||||||
Shell Material | PC＋ABS Anti-flaming | ||||||
Dim. H × W × D (mm) | 86 x 86 x 12.5 | ||||||
Protection Class | IP30 | ||||||
