Vehicle Mounted Well Drilling Workover Rig For High Quality Oil Field
- Category: >>>
- Supplier: Zhengzhou Hanfa Prospecting Machinery Co. Ltd.
Share on (1601196179535):
Product Overview
Description
Product Introduction
Mean application
Used for workover with:8500m depth, oil, water, oil, drilling for: water, gas.
Product Outline
HFXJ1600 is a kind of Truck-mounted workover equipment, Maximumhook load 1580KN, mast height 35m, workover depth 8500m (76mmEUE), nominal workoverdepth 5500m(3-1/2 drilling pipe),drilling depth 2500m(114DP).
Liquid and gas control system: hydraulic pumps, reliable performance, the use of gascontrol valve with manual dual control structure, simple operation and effort, pipeline layoutand concise.
Two parts: Special- purpose chassis, drive type 12*8; special working equipment forworkover.
The mast is structural mast, the hydraulic cylinder carries out lifting. Slant degree: 3.3°the mast upper body bearing unit equipped with cylinder bearing organ that is the turning blocktype, which structure is simple, safe and reliable.
Drawworks: Single drum structure, maximum capacity 210 KN, band or disc brake, thestructure are compact, the efficiency is high, the service life is long.
Liquid and gas control system: hydraulic pumps, reliable performance, the use of gascontrol valve with manual dual control structure, simple operation and effort, pipeline layoutand concise.
Technical Date
Model | HFXJ1600 |
Max Static Hook Load (KN ) | 1580 |
Rated Hook Load (KN) | 1200 |
Hook Speed m/s | 0.11-1.15 |
Travelling System | 4x5 |
Mast Height (m) | 35( Double-section, hydraulic telescopic ) |
Drive Type | 12x8 |
Wire-line diameter mm | φ26 φ29 |
Travel Speed km/h | 0-45 |
Minmum Clearance from the Ground(mm) | 300 |
Min turnning radius (m ) | 19 |
Full Weight(kg) | 65000 |
Total Power(hp) | 600 |
Length(mm) | 20500 |
Width(mm) | 2550 |
Height(mm) | 4000 |
Workover Depth (m) | 8500 |
Kindly let us know your project demands, like drilling depth, depth or more information. We will provide the complete solution for you. Click here to quickly communicate with us!!
WhatsApp：+8617739786040
E-mail：info@hanfagroup.com
phone：0086-371-55019599
Company Introduction
FAQ
1. Are you a trading company or a manufacturer?
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
We are a professional manufacturer. Our factory mainly produces water well drilling rigs, core drilling rigs, down-the-hole drilling rigs, pile drivers, etc. The products have been exported to hundreds of countries around the world and enjoy a high reputation all over the world.
2. How is the quality of your machine?
Our products pass strict quality inspections before they leave the factory to ensure that they are qualified before they are shipped.
3. How to inspect the goods?
1) Support customers to come to the factory for on-site inspection.
2) Support customers to designate third-party companies to inspect goods.
3) Support video inspection.
4. Do you have after-sales service?
Yes, we have a dedicated service team that will provide you with professional technical guidance. If you need, we can send our engineers to your workplace and provide training for your employees.
5. How about quality assurance?
We provide a one-year quality guarantee for the main machine of the machine.
6. How long is your delivery cycle?
1) In the case of stock, we can deliver the machine within 7 days.
2) Under standard production, we can deliver the machine within 15-20 days.
3) In the case of customization, we can deliver the machine within 20-25 days.
