Integrated residential modular building container
- Category: >>>
- Supplier: Dezhou Sailing Import And Export Co. Ltd.
Share on (1601197920086):
Product Overview
Description
Specification
product name | Environmental measurement and control Explosion-proof analysis of cabin containers |
material quality | 304 stainless steel and carbon steel |
skeleton | 10 # to 12 # channel steel or I-beam |
floor | Made of 4-6mm steel plates |
Distribution facilities | Explosion proof electrical |
External dimensions | Determine based on user needs |
Lightning Protection Level | Level 4 |
Product Description
Explosion-proof container is a kind of high-quality cabinet that can store dangerous chemicals, which is generally equipped with leakage system and alarm system as well as temperature control system and monitoring system on the basis of ordinary containers In order to effectively control the temperature of some chemicals in the container and ensure that such chemicals in the case of abnormal timely warning. Containers are mainly used to store items in flammable and explosive fields, and must also be Certified by a professional certification body. Explosion-proof container suitable for petrochemical, metallurgy, military,pharmaceutical, airport and other enterprises IIA, IIB class T1~T4 group of explosive gas environment of composite material repair workshop, Control room, laboratory, warehouse, gas station, oil well platform, oil mining and smelting and other dangerous areas are used in Zone 2
Product Process
The outer cabinet of the explosion-proof box is composed of profiles and plates of carbon steel, stainless steel and other related materials, as well as special hinges and corner parts of the container, and the materials are in line with the detection of relevant national institutions. The coating color of the cabinet and its components is uniform, the thickness is uniform, the
surface is smooth and smooth, and it is easy to clean; The coating structure is the bottom layer, the middle layer and the surface layer, the coating according to the national standard anticorrosion standard, C3-C5 level, to meet the requirements of GB 50046 in the strong corrosion environment of more than 25 years
surface is smooth and smooth, and it is easy to clean; The coating structure is the bottom layer, the middle layer and the surface layer, the coating according to the national standard anticorrosion standard, C3-C5 level, to meet the requirements of GB 50046 in the strong corrosion environment of more than 25 years
Fire Fighting System
A corresponding number of automatic fire extinguishing devices are installed inside the box. When the temperature reaches 68
degrees Celsius, the temperature sensing element explodes for automatic fire extinguishing.
degrees Celsius, the temperature sensing element explodes for automatic fire extinguishing.
Lighting System
he cabinet is equipped with a sufficient number of explosion-proof lighting fixtures. It can prevent the arc, spark and high
temperature that may occur inside the lamp to ignite the flammable gas and dust in the surrounding environment, so as to achieve
explosion-proof
temperature that may occur inside the lamp to ignite the flammable gas and dust in the surrounding environment, so as to achieve
explosion-proof
Ventilation System
Explosion-proof exhaust fans or explosion-proof axial flow fans have air volume greater than 12 air changes per hour. The cabinet is equipped with interlocked ventilation and fireproof louvers, which can be adjusted and controlled according to temperature or
humidity control inside the box. It is equipped with insect and waterproof functions.
humidity control inside the box. It is equipped with insect and waterproof functions.
Explosion-proof air conditioning:
The box is equipped with corresponding brand explosion-proof air conditioning, and interlocked with temperature and humidity sensor, with preset temperature control and energy saving.
The box is equipped with corresponding brand explosion-proof air conditioning, and interlocked with temperature and humidity sensor, with preset temperature control and energy saving.
Alarm System
Inside the box, when the temperature and humidity detector detects that the internal temperature and humidity exceed the set value, a strong audible and visual alarm will be issued, and the detector will trigger the explosion-proof sound . The optical alarm light gives an audible and visual alarm, while the explosion-proof air conditioner is started for ventilation, and the temperature and humidity inside the storage cabinet are reduced
Product Features
1. Strong mobility: movable, easy to lift.
2. Rapid construction: short manufacturing period, no foundation.
3. Safety: steel structure, windproof, shock-proof
4. Beautiful appearance (box color optional)
5. Durability: Steel plate outer wall, corrosion resistance, acid resistance, high weather resistance service life of more than 20 years.
Related Products
Anaerobic Explosion-proof Container
Steam Generating Container
Nitrogen Equipment Container
Living Container
Hazardous & Chemicals Container
Fumigation Equipment Container
Real Fire Test container
Chemical Analysis Container
Prefabricated Cabin
Packing & Delivery
Company Profile
The company mainly operates special equipment containers such as electrical equipment boxes, water treatment equipment containers, functional containers, power generation containers, and power prefabricated cabins, as well as container-type mobile houses, camping containers, modular containers, and ordinary land transportation containers (standard containers and non-standard containers) , professional manufacturing of wingspan containers, and sales of various accessories for containers. Our company has a complete production process, including shearing, stamping, partial assembly, final assembly, welding, sandblasting, painting, decoration, etc., all processed and produced by well-trained professional production workers with rich technical and practical experience.
