Price:$82,100.00 - $86,900.00

Quantity:


Product Overview

Description







Name
Parameters
Unit
Remarks
Punching force
250（25））300（30）
KN（T）
1200Nm,1,500Nm
Frame structure
“O” type closed frame
Primary positioning
Max. machined plate size
X-axis 2,500
mm
(X-axis secondary positioning machinable
5,000mm)
Customizable
Y-axis 1,250/1,500/2,000/2500
mm
Max. machined plate thickness
6
mm
Max. diameter of one punch
Φ88.9
mm
Customizable
Max. punching frequency
1,800
hpm
Max. number of punches
800
hpm
Number of controlled axes
5 (X, Y, T, C, R)
Pcs
Mold type
Long guide 85 series international standard mold
Turret station distribution
16A, 11B, 3C, 2D
(Including rotary stations 1B and 1C)
Standard
Customizable
Repositioning cylinder
2
Set
Number of clamps
3
Pcs
Max. feeding speed
X-axis 80
m/min
Y-axis 80
m/min
Workbench structure
Brush/universal steel ball bench top
Stainless steel wrap
Max. turret speed
40
rpm
Processing accuracy
±0.1
mm
Max. load bearing
150
Kg
Combined power/
Overall power
5/
71.5
KW
Air source pressure
0.55
MPa
Power supply
380±5%
V
Dimensions
L×W×H
5,000/5,500/6,500/7800×5200×2,100
mm




No
Name
Model
Supplier Brand
1
Control system (host computer)
RACK-310 Workstation
 IEI
2
Feeding and drive servo
MDMF/MDDLN
Panasonic, Japan
3
Main servo motor
SM360-30T
Synmot, Ningbo
4
Linear guide rail
TRH30VL/35VL/45VL
TBI, Taiwan
5
Ball screw
5050
TBI, Taiwan
7
Lead screw support bearing
7207C
NSK, Japan
6207
8
Turntable support bearing
HR30220J
NSK, Japan
9
Coupling
P80-114 22/35
Taiwan Jianxiang
10
Reducer
Turbine worm reducer
Hangzhou Tianmai
11
Solenoid valve
4V220-08
AirTAC, Taiwan
4V210-08
12
Pneumatic element
CDQ2B 50X35
AirTAC, Taiwan
13
Proximity switch
04-NPN
Omron, Japan
14
Electrical parts
Contactor, circuit breaker
Schneider
Dry-type isolation transformer
Shanghai Wenfeng




















1. Are you a trading company or manufactuer ?
We are factory, so we have competitive price and we have our own foreign trade team so we also have attentive service.

2. What is the average lead time ?
For samples, the lead time is about 7 days. For mass production, the lead time is 45-60days after receiving the deposit payment.

3. Are you an ODM OR OEM factory?
YES , we are ODM ,you can send us your requirements then we can design for you .

4.What kinds of payment methods do you accept?
You can make the payment to our bank account, Western Union or PayPal:30% deposit in advance, 70% balance against the copy of B/L.

5.Do you provide overseas after-sales service and installation and commissioning services?
Yes , we can. After the equipment arrives at the customer’s site, the company will send its full-time personnel to conduct
installation and commissioning, and provide training for the operators until they can operate the equipment by themselves.

6. What can you buy from us?
CNC Turret Punch Press,CNC bending machine,Fiber Laser Cutting Machine,Bending Automation,Flexible Manufacturing System,Panel bender and sheet plate automatic production lines.

7. What services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR;RMB
Accepted Payment Type: T/T,L/C;
