48 port 10 Gigabit Data Switch Enterprise Network Switch CE6865E 48S8CQ B

Share on (1601200061084):


Price:

Quantity:


Product Overview

Description



Products Description


CloudEngine 6865E series switches are next-generation 25GE Ethernet switches designed for data centers and highend campus networks, providing high-performance, high-density 25GE ports, and low latency. The CloudEngine 6865E series have advanced hardware architecture with 100GE uplink ports and high-density 25GE access ports. Using the HW VRP8 software platform, CloudEngine 6865E series provide extensive data center service features and high stacking capability. In addition, the airflow direction (front-to-back or back-to-front) can be changed. CloudEngine 6865E series can work with CloudEngine 16800 or CloudEngine 12800 switches to build an elastic, virtualized, high-quality 100GE fullyconnected fabric that meets the requirements of cloud-computing data centers. CloudEngine 6865E series provide high-density 10GE/25GE access to help enterprises and carriers build a scalable data center network platform in the cloud computing era. They can also be used as aggregation or core switches for enterprise campus networks


Details Images




Specification


Product Specifications
Item
CE6865E-48S8CQ-B
Physical features
Dimensions (W x D x H)
442 mm x 420 mm x 43.6 mm
Weight
8.8 kg
Switching capacity
4 Tbit/s
Forwarding performance
2000 Mpps
10/25GE SFP28 ports
48
100GE QSFP28 ports
8
Management interface
Out-of-band management port
1 x GE management interface
Console port
1 x RJ45 interface
USB port
1
CPU
Main frequency (GHz)
1.5
Number of cores
8
Storage
RAM
4 GB
NOR flash
32 MB
NAND flash
2 GB
System
System buffer
32 MB
Power supply system
Power modules
600 W AC/600 W -48 V DC
Rated voltage range (V)
100 V to 240 V AC
–48 V to –60 V DC
Maximum voltage range
(V)
690 V to 290 V AC
–38.4 V to –72 V DC
Typical power
265 W (100% traffic load, copper cable, normal temperature, dual power modules)
327 W (100% traffic load, short-distance optical transceivers, normal temperature, dual power modules)
