Electric propelling applications | Engine starting battery; Slow Speed Car; Intellectual robots; Electric bicycle/Motorcycle/Scooter; Golf trolley/Carts/ Sightseeing car; Power tools. |
Energy storage | solar and wind power system; city on/off grid; community and family, RV Caravan, Marine yachts. |
Back-up system and UPS | telecom base, CATV-system, computer server center, medical instrument, military equipment. |
Other applications | security and electronics; mobile POS, mining light/torch/LED light/emergency light. |
Nominal Capacity | 4000mAh(0.2C,2.5V discharge) |
Minimum Capacity | 3950mAh(0.2C,2.5V discharge) |
Rated Capacity | 3C,2.75V discharge ≥3792mAh 96%Capacity of min 5C,2.75V discharge ≥3753mAh 95%Capacity of min 8C,2.75V discharge ≥3753mAh 95%Capacity of min 10C,2.75V discharge ≥3753mAh 95%Capacity of min |
Nominal Energy | 14.4Wh(0.2C,2.5V discharge) |
Nominal Voltage | 3.60V(0.2C,2.5V discharge) |
Standard Charge | Method: CC-CV Charging Voltage: 4.20V Charging Current: 0.5C ( 2000mA) Cut-off Current: 0.01C (40mA) |
Maximum Charge Current | 1.0C (4000mA),for continuous charge |
Standard Discharge | Method: CC Discharge Cut-off Voltage: 2.5V Discharging Current: 0.2C(800mA) |
Maximum Discharge Current | 10.0C(40000mA) 10.0C(40000mA),for continuous discharge |
Weight | 45g±2g |
Operating Temperature,Charge | 0~45℃ |
Operating Temperature,Discharge | -20~60℃ |
Storage Temperature | 1 month:-20~45℃ 3 months:-20~35℃ 1 year:-20~25℃ |
