Steel-Lined Tetrafluoro Pipe Fittings Design Features

 Jiangsu Yihao Plastic Manufacturing Co., Ltd. presents high-performance Steel-Lined Tetrafluoro Pipe Fittings designed with utmost precision and quality.

Key Features:

 1.Seamless construction ensures durability, impact resistance, and aging resistance.

2.Excellent axial tensile strength for enhanced reliability.

3.Smooth surface allows for lining any shaped steel parts.

Steel Pipe Lined PTFE for Pipe Fittings

Brand: YIHAO

Material: Carbon Steel, Stainless Steel, PTFE

DN: DN20-DN1200, 3/4"~20"

Working Temperature: -20ºC~180ºC

Working Pressure: 0 ~2.5Mpa

Flange: According to T20592-2009)

According to different requirement standard of GB, JB, ANSI, JIS, BS, DIN are optional, fixed flange, flexible flange are available.

Medium: Can transport any concentration of strong acid, strong alkali, organic solvent, strong oxidant, toxic and other corrosive medium.

Product descriptions from the supplier

Overview

PFA PO PTFE Lined Fittings

PTFE Lined Pipe Fittings for gas oil

Technical Specification
Design and Manufacture: ASTM F1545-97
Flange Standard: ASME/ANSI 16.5, DIN, JIS
Inspection and testing: ASTM F1545-97

Product Specification
Pipe Material: ASTM A106
Lining Material: PTFE, PFA, PO
Flange Material: SS304, SS304L, SS316, SS316L, ASTM A3
Nominal Diameter: NPS 1-40
Pressure Range: 150lb 300lb JIS 10k, DIS
Connection Type: Flange connection
Product description:
1. Yihao manufactures lined pipe and fittings by use compression molding, isostatic molding, injection molding, transfer molding, hot rotomolding, ram/paste extrusion, 3D rotational molding etc.

Characters as below:

2. Working temperature is high at the range of -29℃-200℃; Except the molten alkali metals, element fluorine and aromatic hydrocarbon, lined products can be used in any chemical medium.
3. Vacuum resistance. In the range of -29℃-150℃, it is applicable for vacuum condition. In chemical production, the vacuum condition occurs due to cooling, longitudinal emissions, or medium backflow.
4. High-pressure resistance. Within temperature working condition, it can sustain the working pressure of 3.0MPa.
5. Resistance to penetration. Adapt the high-quality PTFE, to make it of high density and enough thickness after advanced lining processing, make it excellent anti-osmosis.
6. PTFE advanced lining molding process achieved the status of synchronous hot expansion or cold shrinkage for steel components and fluorine plastic.
7. Kingmetal adopts the standard size according to HG, GB, DIN, ANSI, and JIS etc., which improves interchangeability, to provide convenience for installation.
8. Specific gravity: 2.14-2.19g/cm3 as per ASTM D 792 test standard.
9. Tensile rate: 20.7Mpa minimum as per ASTM D 638 test standard
10. Elongation rate: 250% minimum as per ASTM D 638 test standard.
11. Manufacture standard: ASTM D 4895. Operating in vacuum condition within 150oC.
We are manufacturer specializing in:
1. PTFE/PFA/PO/ Lined Valve(Including butterfly valve, ball valve, gate valve, check valve, globe valve, diaphragm valve, plug valve etc. )
2. PTFE/PFA/PO Lined Pipe and Pipe Fitting (Including Spool, Elbow, Tee, Cross, Reducer, Instrument Connector, Blind Flange, Strainer, Sight Glass etc)

Please note:

When the diameter DN ≥ 500mm, it belongs to the equipment category.

1.If it is used under negative pressure, please explain when ordering, and then lining will be carried out according to the negative pressure resistant process.

2.If there is no special requirement for the flange, please refer to the appendix according to the regulations of HG20592-2009.

3.The parameters of the common pipe fittings are shown in the table. Other non-standard parts such as eccentric reducers, different diameter elbows, etc. can be processed according to user requirements.

4.Steel lining F4, F46 glass cylinder mirror pressure <0.3MPa, working conditions pressure ≥ 0.3Mpa, the customer is recommended to use steel-lined PTFE four-way mirror.

5.Steel-lined PTFE molded parts DN ≥ 200, the use temperature <120 ° C, the use pressure -0.02-1.6Mpa, can be specially designed according to customer conditions.
