12 Port Mini ODF Wall Mount ST Fiber Patch Panel Fiber Termination Box Optical Terminal Box TJ01E12ST
- Category: >>>
- Supplier: Ningbo Fibertel Communication Technology Co. Ltd.
Share on (1601200445591):
Product Overview
Description
Product Description
Description
The product can be used indoors, outdoors, CAT and so on. It suits for different type of optical cables (Φ≦18mm).
Features
* All property indexes are in accordance with National YD/T925—1997 Standard.
* The box body is made of high-quality engineering plastics.
* Distinctive design of 1-2 cable entrance and fiber exit of 1-12 cores assures flexibility.
* Overlapping splice trays make the optical fiber configuration, expanding the core capacity convenient.
The product can be used indoors, outdoors, CAT and so on. It suits for different type of optical cables (Φ≦18mm).
Features
* All property indexes are in accordance with National YD/T925—1997 Standard.
* The box body is made of high-quality engineering plastics.
* Distinctive design of 1-2 cable entrance and fiber exit of 1-12 cores assures flexibility.
* Overlapping splice trays make the optical fiber configuration, expanding the core capacity convenient.
Specification
Item | Indoor Wall Mounted Plastic Terminal Box | ||||||
Part No. | TJ01E12FC | TJ01E12ST | TJ01E08SC | TJ01E0812 | |||
Fiber capacity | 12 fibers | 12 fibers | 8 fibers | 8/12 fibers | |||
Adapter type | FC | ST | SC/LC | FC/ST/SC/LC | |||
Product Size(mm) | 285*132*46 | ||||||
Out package size(mm) | 630*330*340 | ||||||
Out package weight | 11.5kg | ||||||
Inner package net weight | 0.5kg | ||||||
Packing quantity | 20pcs | ||||||
Working temperature | -40℃~+60℃ | ||||||
Minimal fiber winding radius | ≤30mm | ||||||
