POM engineering plastic FM2020BK molybdenum disulfide pom high wear resistant pencil black raw material manufacturers wholesale
- Category: >>>
- Supplier: Shanghai Xingshengyuan Plastic Products Co. Ltd.
Share on (1601201329996):
Product Overview
Description
Product Description
Physical properties | rating | Units | Test methodology | |
specific gravity | 1.41 | g/cm³ | ASTM D792, ISO 1183 | |
Melting rate (melt flow rate) (190°C/2.16 kg). | 9 | g/10 min | ISO 1133 | |
Shrinkage - flowing | 1.6 to 2.0 | % | Internal methods | |
Water absorption (23°C, 24 hr, 50% RH). | 0.2 | % | ASTM D570 | |
hardness | rating | Units | Test methodology | |
Rockwell hardness | ASTM D785 | |||
Class M | 80 | ASTM D785 | ||
Class R | 115 | ASTM D785 | ||
Mechanical properties | rating | Units | Test methodology | |
Tensile modulus | 2700 | MPa | ISO 527-2 | |
Tensile stress | ||||
succumb | 63 | MPa | ISO 527-2 | |
-- | 63 | MPa | ASTM D638 | |
Elongation (fracture). | 35 | % | ASTM D638, ISO 527-2 | |
Flexural modulus | ||||
-- | 2550 | MPa | ASTM D790 | |
-- | 2500 | MPa | ISO 178 | |
Bending strength | 90 | MPa | ASTM D790 | |
Tabor wear resistance | 14 | mg | ASTM D1044 | |
Impact performance | rating | Units | Test methodology | |
Simple support beam notched impact strength | 7 | kJ/m² | ISO 179 | |
Cantilevered notch impact strength | 77 | J/m | ASTM D256 | |
Thermal performance | rating | Units | Test methodology | |
Heat deflection temperature under load | ||||
0.45 MPa, unannealed | 158 | °C | ASTM D648 | |
0.45 MPa, unannealed | 156 | °C | ISO 75-2/B | |
1.8 MPa, unannealed | 110 | °C | ASTM D648 | |
1.8 MPa, unannealed | 100 | °C | ISO 75-2/A | |
Linear coefficient of thermal expansion - flowing | 1.00E-04 | cm/cm/°C | ASTM D696, ISO 11359-2 | |
specific heat | 1470 | J/kg/°C | ||
Thermal conductivity | 0.23 | W/m/K | ||
Electrical performance | rating | Units | Test methodology | |
Surface resistivity | 1.0E+16 to 1.0E+17 | ohms | ASTM D257 | |
Volume resistivity (23°C). | 1.0E+15 to 1.0E+16 | ohms·cm | ASTM D257 | |
Dielectric strength | 19 | kV/mm | ASTM D149 | |
Dielectric constant (23°C, 1 MHz). | 3.9 | ASTM D150 | ||
Dissipation factor (23°C, 1 MHz). | 8.00E-03 | ASTM D150 | ||
Arc resistance | 250 | sec | ASTM D495 | |
flammability | rating | Units | Test methodology | |
UL flame retardant rating | UL 94 | |||
0.750 mm | HB | UL 94 | ||
1.50 mm | HB | UL 94 |
Specification
characteristic
characteristic
1. Highly crystalline resin with balanced mechanical, chemical, thermal and electrical properties 2. Excellent rigidity, creep
resistance and fatigue resistance
3. Low friction coefficient and low wear
speed
4. Small coefficient of thermal expansion, dimensional stability
Excellent 5. Oil and organic solvent resistance
6. Excellent fluidity and formability
1. Highly crystalline resin with balanced mechanical, chemical, thermal and electrical properties 2. Excellent rigidity, creep
resistance and fatigue resistance
3. Low friction coefficient and low wear
speed
4. Small coefficient of thermal expansion, dimensional stability
Excellent 5. Oil and organic solvent resistance
6. Excellent fluidity and formability
