High quality Seismic support system accessories Plastic wing nut for piping support
- Category: >>>
- Supplier: Hebei Hekang Metal Products Co. Ltd.
Share on (1601201454016):
Product Overview
Description
Seismic support fittings-Plastic wing nut | ||||||||
Product model | Available color | Material | Product size/CM | Net weight | ||||
SYLM-M12*8 | silvery white | carbon steel | 1.2*0.8 | 0.033kg | ||||
Seismic support | ||
Description | Seismic support is a seismic support system with seismic force as the main load, which is used to support water pipes, air pipes, Bridges and other electromechanical pipeline equipment and provide seismic support products. | |
Function | The installation of seismic support can avoid and reduce the earthquake damage to the mechanical and electrical equipment in the building, reduce the harm of the earthquake, and protect the safety of people's lives and property. | |
Structure composition | The seismic support is composed of anchor solid, reinforced boom, seismic connecting member and seismic diagonal brace. | |
Standard definition | According to GB50981-2014 "Code for Seismic Design of Building Mechanical and Electrical Engineering", seismic support is defined as "a seismic support facility firmly connected to the building structure with seismic force as the main load". | |
Usage requirements | All components of the seismic support and hanger should be finished components, except C-channel steel and full-thread boom can be cut off on site, and other products should not be carried out on-site work. | |
More products... Seismic support installation diagram | ||
Single tube lateral support
(lateral)
(lateral)
Serial number | Bracket name | name | Specification and model |
1 | HS-01 | Single pipe lateral support (T) | DN65 |
2 | HS-02 | Single pipe lateral support (T) | DN80 |
3 | HS-03 | Single pipe lateral support (T) | DN100 |
4 | HS-04 | Single pipe lateral support (T) | DN125 |
5 | HS-05 | Single pipe lateral support (T) | DN150 |
6 | HS-06 | Single pipe lateral support (T) | DN200 |
7 | HS-07 | Single pipe lateral support (T) | DN250 |
8 | HS-08 | Single pipe lateral support (T) | DN300 |
9 | HS-09 | Single pipe lateral support (T) | DN350 |
Single tube bidirectional support (lateral + longitudinal)
Serial number | Bracket name | name | Specification and model |
1 | HS-01A | Single tube bidirectional support (T+L) | DN65 |
2 | HS-02A | Single tube bidirectional support (T+L) | DN80 |
3 | HS-03A | Single tube bidirectional support (T+L) | DN100 |
4 | HS-04A | Single tube bidirectional support (T+L) | DN125 |
5 | HS-05A | Single tube bidirectional support (T+L) | DN150 |
6 | HS-06A | Single tube bidirectional support (T+L) | DN200 |
7 | HS-07A | Single tube bidirectional support (T+L) | DN250 |
8 | HS-08A | Single tube bidirectional support (T+L) | DN300 |
9 | HS-09A | Single tube bidirectional support (T+L) | DN350 |
Multi-tube lateral support (lateral) | ||||||
Serial number | Bracket name | name | Specification and model | |||
1 | HZ-01 | 2-tube assembly | Default DN100 | |||
2 | HZ-02 | 3-tube assembly | Default DN100 | |||
3 | HZ-03 | 4-tube assembly | Default DN100 | |||
4 | HZ-04 | 5-tube assembly | Default DN100 | |||
5 | HZ-05 | 6-tube assembly | Default DN100 | |||
Multi-tube combination bidirectional support (lateral + longitudinal) | ||||||
Serial number | Bracket name | name | Specification and model | |||
1 | HZ-01a | 2-tube assembly | Default DN100 | |||
2 | HZ-02a | 3-tube assembly | Default DN100 | |||
3 | HZ-03a | 4-tube assembly | Default DN100 | |||
4 | HZ-04a | 5-tube assembly | Default DN100 | |||
5 | HZ-05a | 6-tube assembly | Default DN100 | |||
Integrated system lateral support (lateral) | ||||||
Serial number | Bracket name | name | Specification and model | |||
1 | HZ-01 | Composite support 1 | Default DN150 | |||
2 | HZ-02 | Composite support 2 | ||||
3 | HZ-03 | Composite support 3 | ||||
4 | HZ-04 | Composite support 4 | ||||
5 | HZ-05 | Composite support 5 | ||||
Integrated system bidirectional support (lateral + vertical) | ||||||
Specification and model | ||||||
1 | HZ-01a | Composite support 1 | ||||
2 | HZ-02a | Composite support 2 | ||||
3 | HZ-03a | Composite support 3 | ||||
4 | HZ-04a | Composite support 4 | ||||
5 | HZ-05a | Composite support 5 | ||||
Q1：Can you provide samples? Is the sample free?
A1：We can provide samples. Sample is not free. But we can reduce the cost in the next order.
Q2：How does your factory do the quality control?
A2：We have quality inspection department, each process has the corresponding quality control standards, each workshop is equipped with quality inspection personnel.
Q3：Do you have the products in stock?
A3：Yes, Only a little , Our company provides customized products.
Q4：Can you provide OEM / ODM service？
A4：Yes, We can do OEM and ODM.
A1：We can provide samples. Sample is not free. But we can reduce the cost in the next order.
Q2：How does your factory do the quality control?
A2：We have quality inspection department, each process has the corresponding quality control standards, each workshop is equipped with quality inspection personnel.
Q3：Do you have the products in stock?
A3：Yes, Only a little , Our company provides customized products.
Q4：Can you provide OEM / ODM service？
A4：Yes, We can do OEM and ODM.
