  • UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w 1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w 1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w-1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w-1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w-1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w-1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w-1.5w 275nm Wavelength UVC LED Chip
UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w-1.5w 275nm Wavelength UVC LED Chip

UVC LED Chip for Hot Product Air Water Purifier 6565 0.5w 1.5w 275nm Wavelength UVC LED Chip

Share on (1601202039254):


Price:$4.00 - $5.00

Quantity:


Product Overview

Description



Details Images




Specification


Type
UVC SMD LED
Model
ZL-6565N2U12-275
Description
SMD6565 UVC LED
Origin
Guangdong, China
Brand Name
ZL
Dominant Wavelength
270 - 280nm
Encapsulation Size
 6.50*6.50*4.5mm
Encapsulation
Ceramic Substrate
Forward Voltage
10 ~ 15V
Peak Forward Current
240 ~ 300mA
Optical Power
60 ~ 80mW
Operating Temperature Range
 -20℃ to +80℃
Storage Temperature Range
 -40℃ to +100℃
 Lead Soldering Temperature
260℃
View Angle
120 deg
Customization
Available
Application
Sterilization，Purifier
Packaging Details
1000pcs/bag, ESD bag, Carton box
