High Precision Manual Bench Lathe Machine Normal Torno lBench Mechanical Turning Horizontal Metal Manual Lathe Machine Price
- Category: >>>
- Supplier: Almaco Machine Tool Co. Ltd.
Share on (1601207011341):
Product Overview
Description
Recommend Products
Products Description
Introduction
A lathe is a machine tool that mainly uses a turning tool to turn a rotating workpiece. Drills, reamers, reamers, taps, dies and knurling tools can also be used on the lathe for corresponding processing.
◆Precision ground and hardened bedways
◆The spindle is supported with precision roller bearings
◆Head stock gears are made of high quality steel ground and hardened
◆Easy operating speed change levers
◆Easy operating gear box has various feeds and thread cutting function
◆Right angle appearance or circular appearance for optional
◆52mm Big spindle bore for optional
Specification
ITEMS | METRIC | INCH | |
Max swing over bed | 356mm | 14" | |
Max swing over cross slide | 220mm | 8-5/8" | |
Max swing over gap | 506mm | 20" | |
Width of bed | 206mm | 8-1/9" | |
Distance between center | 1000mm | 40 | |
Taper of spindle hole | M.T.NO.5 | ||
Hole through spindle | 38mm or 52mm (optional) | 1-1/2" or 2-2/5"(optional) | |
Step of spindle speed | 8 or 16 steps | ||
Range of spindle speeds | 90 or 45-1800 r.p.m | ||
Spindle nose | D1-4 or D1-5 | ||
Metric thread range | (37) 0.4-7mm | (22)0.45-7.5mm | |
Whitworth threads range | (28)4-56T.P.1 | (40)4-112T.P.I | |
Range of longitudinal feeds | (42)0.043-0.653mm/rev | (40)0.0304- 0.746mm/rev | |
Range of cross feeds | (42)0.0017-0.0257in/rev | (40)0.0012-0.0294in/rev | |
(42)0.015-0.22mm/rev | (40)0.0076-0.254mm/rev | ||
(42)0.0006-0.0087in/rev | (40)0.0003-0.0100in/rev | ||
Pitch and diameter of leadscrew | 4mm | 8T.P.I | |
Travel of carriage | 840mm | 33 " | |
Travel of cross slide | 178mm | 7" | |
Travel of top slide | 92mm | 3-5/8" | |
Travel of tailstock quill | 115mm | 4-1/2" | |
Diameter of tailstock quill | 45mm | 1-25/32" | |
Taper of tailstock quill | M.T.NO.3 | ||
Motor power | 2/3.3HP | ||
Net weight | 750KG | 1667LBS | |
Packing size | 1950*760*1480mm | 76-25/32"*30"*58-8/30" | |
Company Profile
Our Service
Overseas after sales service outlets
TOPTECH SMAC MACHINERY LIMITED（Canada）
Address:Office and showroom, unit 5, 5510 Ambler Dr Mississauga, ON, L4W2V1, CANADA
Office:905 238 8912
Contact: Mrs Merry NA
COMPANY REPRESENTATIVE (EGYPT)
Address: Ibn Khaldon St. -Villa No.16-6th District-Obour City-Cairo-Egypt
Tel & Fax: +20244823499
Cell phone: +201223960211
Contact: Ahmed Refaat
SJR MACHINERY LIMITED（Algeria）
Adress: cité 128 logements Bater numéro 71 Sidi el DJILLALI sidi bel abbes 22000 att to Mr mezouar Mohammed
mobile number 0542 695 457 and 0770 551 807
Tel: 0542 695 457 ,0770 551 807
Email:Mezouarstar@gmail.com
TOPTECH SMAC MACHINERY LIMITED（Canada）
Address:Office and showroom, unit 5, 5510 Ambler Dr Mississauga, ON, L4W2V1, CANADA
Office:905 238 8912
Contact: Mrs Merry NA
COMPANY REPRESENTATIVE (EGYPT)
Address: Ibn Khaldon St. -Villa No.16-6th District-Obour City-Cairo-Egypt
Tel & Fax: +20244823499
Cell phone: +201223960211
Contact: Ahmed Refaat
SJR MACHINERY LIMITED（Algeria）
Adress: cité 128 logements Bater numéro 71 Sidi el DJILLALI sidi bel abbes 22000 att to Mr mezouar Mohammed
mobile number 0542 695 457 and 0770 551 807
Tel: 0542 695 457 ,0770 551 807
Email:Mezouarstar@gmail.com
Packing & Delivery
We choose the best packaging, the most excellent
logistics services, to ensure that your goods faster and safer to reach the destination.
logistics services, to ensure that your goods faster and safer to reach the destination.
FAQ
Q.What are your normal lead times?
A.Our company typical lead times range from 3-4weeks after receipt of order.
Q.What are the terms of payments you offer?
A.We accept payment of T/T, L/C, and Western Union, cash, O/A etc.
Q.What kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition.
Q.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.
Q.Do you have CE certification
A.Yes, we have CE certification, machine quality is one year guaranteed.
Q.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service".
A.Our company typical lead times range from 3-4weeks after receipt of order.
Q.What are the terms of payments you offer?
A.We accept payment of T/T, L/C, and Western Union, cash, O/A etc.
Q.What kind of package do you offer?
A.Normally in plywood case, to make sure all goods in good condition.
Q.What is the MOQ for your production?
A.The MOQ depends on your requirements for color, logo and so on. For some normal items, we have in stock, the MOQ is 1 set.
Q.Do you have CE certification
A.Yes, we have CE certification, machine quality is one year guaranteed.
Q.How to control the quality of the products?
A.We have always placed great emphasis on the quality level is maintained. Moreover, the principle we always maintain is "to provide customers better quality, better price, and better service".
