P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room
P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room
P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room
P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room
P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room
P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room
P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room

P0.93 P1.25 P1.8 P1.56mm Fine Pitch Fixed LED Screen Panel Indoor Fine Pitch LED Display Screen For Conference Monitor Room

Share on (1601207331035):


Price:$239.00 - $259.00

Quantity:


Product Overview

Description







Indoor P1.25
Pixel Pitch:1.25mm
Brightness:50-500cd/㎡ adjustable
Refresh Rate:≥3840HZ
Pixel Matrix Per Sq.m:640,000 dot/m²
Module Dimension:150mm*168.75mm
Cabinet Dimension:600mmx337.5mmx32.5mm (W×H×D)
Cabinet Material:Die Casting Aluminum
Cabinet Weight:4.3Kg
Location:Australia


Indoor P2.34
Pixel Pitch:2.34mm
Brightness:50-500cd/㎡ adjustable
Refresh Rate:≥3840HZ
Pixel Matrix Per Sq.m:182044 dot/m²
Module Dimension:150mm*168.75mm
Cabinet Dimension:600mmx337.5mmx32.5mm
Cabinet Material:Die Casting Aluminum
Cabinet Weight:4.3Kg
Location:USA
Indoor P1.5
Pixel Pitch:1.5mm
Brightness:50-500cd/㎡ adjustable
Refresh Rate:≥3840HZ
Pixel Matrix Per Sq.m:409600 dot/m²
Module Dimension:150mm*168.75mm
Cabinet Dimension:600mmx337.5mmx32.5mm
Cabinet Material:Die Casting Aluminum
Cabinet Weight:4.3Kg
Location:China


Indoor P0.93
Pixel Pitch:1.5mm
Brightness:50-500cd/㎡ adjustable
Refresh Rate:≥3840HZ
Pixel Matrix Per Sq.m:1137778 dot/m²
Module Dimension:150mm*168.75mm
Cabinet Dimension:600mmx337.5mmx32.5mm
Cabinet Material:Die Casting Aluminum
Cabinet Weight:4.3Kg
Location:UK
Indoor P1.87
Pixel Pitch:1.87mm
Brightness:50-500cd/㎡ adjustable
Refresh Rate:≥3840HZ
Pixel Matrix Per Sq.m:284444 dot/m²
Module Dimension:150mm*168.75mm
Cabinet Dimension:600mmx337.5mmx32.5mm
Cabinet Material:Die Casting Aluminum
Cabinet Weight:4.3Kg
Location:USA




Product Paramenters


Item
CV 1.25
CV 1.56
CV 1.87
Pixel Pitch (mm)
1.25
1.5625
1.875
LED Configuration
FLIP CHIPCOB 1R1G1B Common cathode
FLIP CHIPCOB 1R1G1B Common cathode
FLIP CHIPCOB 1R1G1B Common cathode
LED Type
2x4
2x4
2x4
Physical Density (dot/m²)
640000
409600
284444
Module Size (WxHxD)mm
150x168.75
150x168.75
150x168.75
Module Resolution (WxH)
120x135
96x108
80x90
Module Material
No Plastic housing
No Plastic housing
No Plastic housing
Cabinet Size (WxHxD)mm
600x337.5x32.5
600x337.5x32.5
600x337.5x32.5
Cabinet resolution (WxH)dot
480x270
384x216
320x180
Cabinet Material
Die Casting Aluminum
Die Casting Aluminum
Die Casting Aluminum
Scanning Mode
1/45
1/48
1/30
Cabinet Flatness (mm)
≤0.10
≤0.10
≤0.10
Grey Scale (Bit)
14Bit+Control Software 2Bit=16Bit
14Bit+Control Software 2Bit=16Bit
14Bit+Control Software 2Bit=16Bit
Protection Level
LED Lamp side lP65,rear lP45
LED Lamp side lP65,rear lP45
LED Lamp side lP65,rear lP45
Installation/Service Method
Front or back installation/Front service
Front or back installation/Front service
Front or back installation/Front service
Brightness
50-500cd/㎡ adjustable
50-500cd/㎡ adjustable
50-500cd/㎡ adjustable
Color Temperature
3200-9300K adjustable
3200-9300K adjustable
3200-9300K adjustable
Brightness Uniformity
≥98%
≥98%
≥98%
Color Uniformity
Within 0.003Cx,Cy
Within 0.003Cx,Cy
Within 0.003Cx,Cy
Horizontal/ertical View Angle
≥170°
≥170°
≥170°
Contrast Ratio
≥10000:1
≥10000:1
≥10000:1
Color calibration of Single Dot
Yes
Yes
Yes
Brightness Calibration of Single Dot
Yes
Yes
Yes


Products Description




Company Profile








Shenzhen Xinghe Optoelectronics Technology Co., Ltd.
Shenzhen Xinghe Optoelectronics Technology Co., Ltd.has been focusing on the field of LED display for more than 10 years, providing high quality, high brightness and long life display solutions. The company's service areas include advertising media, sports venues, etc., and has a rich product line, such as indoor and outdoor full color screen, monochrome screen and creative shaped screen. We focus on the user experience, using SMD technology, high refresh rate and gray level to ensure smooth and natural picture. Products through ISO9001, CE and other international certification, to meet the high standard of quality requirements. The company's research and development team actively innovates, follows international trends, maintains market leadership, and provides customized services to meet customer needs. Our sales network covers Europe, North America and other places, and has established stable cooperation with a number of retailers and distributors. At the same time, actively participate in domestic and foreign exhibitions to expand market influence. In terms of customer service, we provide comprehensive support from early consultation to late maintenance, and the customer service team answers questions online all day long. The core values of the company are "innovation, integrity, cooperation, win-win". Guided by market and customer needs, the company is committed to creating competitive products and establishing long-term cooperative relations with customers.


Manufacturing Technique






Factory Display






Why Choose Us








Product packaging & Physical Distribution






FAQ


1.Q: What products do you offer?
A:Now we can offer Customized All-in-one machine, Touch screen monitor, Advertising machine, LED screen , Touch kiosk, etc.


2.Q: Can I have the products with my own logo?
A:Yes. We can offer both OEM and ODM service with prototype design and small MOQ.


3.Q: How long can I expect to get the sample?
A:The samples will be ready for delivery in 3—5 days after we receive the payment.


4.Q:Can you give me a discount?
A:Yes, based on wholesale service, we have better discount for bigger quantities. We will quote you the best price based on your order quantity.


5.Q: What is the lead time for mass production?
A:Our fastest lead time is 1-7 days, which will depend on the order quantity.


6.Q:Do you have stock?
A:We keep 2000-5000 units in Stock every single Month.


7.Q: Is your company a real manufacturer?
A: Our company is a professional factory , located in Bao an district, Shen zhen city, China. You are the mostly welcomed to visit our factory anytime.


8.Q: How is the quality of the product?
A: Our products have been strictly tested high quality by QC before shipping to customers.We are adhering to the principle:
"Quality and service are our first priority."


We are online 24 hours a day, welcome to come for cooperation and negotiation!
