Factory Direct Sales Indoor Motorized Movie Screen Big Screen Indoor Led Tv Screen Display Indoor for School
- Category: >>>
- Supplier: Madder Engineering & Technology Co. Ltd.Madder Ltd.
Share on (1601208476711):
Product Overview
Description
Recommend Products
Our Services
Products Description
Product Paramenters
Product name | MDI | ||||||||||||
Model Number | MDI1.5 | MDI1.86 | MDI2 | MDI2.5 | MDI3.076 | MDI4 | MDI5 | ||||||
Pixel pitch (mm) | 1.538 | 1.86 | 2 | 2.5 | 3.076 | 4 | 5 | ||||||
Physical Density (pixels/m²) | 422,500 | 288,906 | 250,000 | 160,000 | 105,625 | 62,500 | 40,000 | ||||||
Size of module | 320mm * 160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | 320mm*160mm | ||||||
Module Resolution | 208*104 | 172 * 86 | 160 * 80 | 128 * 64 | 104 * 52 | 80 * 40 | 64 * 32 | ||||||
Brightness | 600 cd/㎡ | 800 cd/㎡ | 800 cd/㎡ | 800 cd/㎡ | 800 cd/㎡ | 800 cd/㎡ | 800 cd/㎡ | ||||||
Max Power Consumption | 450 W/㎡ | 650 W/㎡ | 650 W/㎡ | 650 W/㎡ | 650 W/㎡ | 650 W/㎡ | 650 W/㎡ | ||||||
Avg.Power Consumption | 150 W/㎡ | 170 W/㎡ | 170W/㎡ | 170W/㎡ | 176W/㎡ | 170W/㎡ | 170W/㎡ | ||||||
Viewing Angle | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | 160°/160° | ||||||
Operating Power Source | AC100-240V 50-60Hz | DC：4.5 ~ 5 V | DC：4.5 ~ 5 V | DC：4.5 ~ 5 V | DC：4.5 ~ 5 V | DC：4.5 ~ 5 V | DC：4.5 ~ 5 V | ||||||
Operating Temperature | -10 °C ~ 40 °C | -10 °C ~ 40 °C | -10 °C ~ 40 °C | -10 °C ~ 40 °C | -10°C~40°C | -10°C~40°C | -10°C~40°C | ||||||
Refresh Rate | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | 3,840Hz | ||||||
Cabinet specifications | 640mm * 480mm * 65mm / 640mm * 640mm * 65mm/ 960mm * 480mm * 65mm / 320mm * 480mm * 65mm / 320mm * 640mm * 65mm | ||||||||||||
Weight | 5kg~11kg | ||||||||||||
Material | aluminum | ||||||||||||
Installation | crane girder hoisting and fixed installation | ||||||||||||
Color | dark gray | ||||||||||||
Working environment | Indoor | ||||||||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
