Skymard XZ430E HDD Horizontal Directional Drilling Machine
- Category: >>>
- Supplier: Skymard Construction Machinery (Hunan) Co. Ltd.Skymard Ltd.
Share on (1601214013642):
Product Overview
Description
Product Overview
Skymard XZ430E HDD Horizontal Directional Drilling Machine
1.The dual-speed carriage is operated with low speed when drilling and dragging back to ensure smooth construction ,and can speed up to slide with 2 times of speed to reduce the auxiliary time and improve the working efficiency when returning and disassembling the drilling rod with empty loads.
PRODUCTS DESCRIPTION
Rubber track: with minimum impact on the pedestrian way, lawn and landscape.
The floating clamp with patent technology can effectively prolong the service life of the pipe.
The floating clamp with patent technology can effectively prolong the service life of the pipe.
Engine model | QSC8.3-C240 |
Rated Power | 179 /2200kW/r/min |
Thrust-Pull Max Force | 430/520kN |
Max Speed | 42m/min |
Pipe | φ83×3000mm×mm |
Track width | 2240 mm |
Rubber track width | 400 mm |
Tread | 2140mm |
Supporting wheels quantity | 2×6 |
Gradeability | 30% |
Walking speed | 2.6km/h |
Ground pressure | 63kPa |
