Best Price Mini Road Roller Compactor Double Drive Small Construction Road Roller Road Roller
- Category: >>>
- Supplier: Jining Xinta Heavy Industry Machinery Co. Ltd.
Share on (1601214205485):
Product Overview
Description
Product Information
Road roller is a heavy engineering machinery widely used in compaction operations of roads, bridges, and other large-scale projects. Their main function is to compact materials such as soil and asphalt through the vibration or static pressure of the grinding wheel, in order to improve their density and strength, and ensure the stability and durability of the engineering structure.
model | speed | Turning radius | Climbing ability | Water tank capacity | Vibration frequency | power | size |
1T(70 in the front, 50 in the back) | 0-56KM/H | / | / | 15L | 70HZ | 4KW | 1850*800*1500MM |
1T | 0-86KM/H | 1550MM | 30% | 34L | 65hz | 6.3kw | 1850*800*1500MM |
1T(Fully hydraulic) | 0-86KM/H | 1530MM | 30% | 36L | 65HZ | 8.2KW | 1865*900*2080MM |
2T | 0-6KM/H | 1760MM | 30% | 130L | 70HZ | 11.5KW | 2300*1130*2400MM |
2.5T | 0-10KM/H | 1750MM | 30% | 70L | 75HZ | 28kw | 2350*1230*2500MM |
3T | 0-10KM/H | 2750MM | 40% | 146L | 55HZ | 28KW | 3028*1330*2500MM |
3.5T(Single steel wheel) | 0-8KM/H | / | 30% | / | 60HZ | 28KW | 3800*1390*2300MM |
3.5T Double steel wheels | 0-12KM/H | 1850MM | 30% | / | 70HZ | 28KW | 3260*1295*2580MM |
4T | 0-18KM/H | 2350MM | 30% | / | 60HZ | 36.8KW | 4500*1650*2670MM |
4T Thomas | / | / | 40-50% | 150L | 65HZ | 36.8KW | 3400*1450*2800MM |
5T | 3000MM | 30% | 200L | 65HZ | 36.8KW | 3320*1600*2650MM | |
6T | 0-15KM/H | 2965MM | 55% | / | 41HZ | 36.7KW | 4535*1820*2760MM |
8T | 0-15KM/H | 2980MM | 55% | / | 50HZ | 76KW | 5100*2010*2670MM |
10T | 0-15KM/H | 3100MM | 55% | / | 70HZ | 85KW | 5610*2300*2700MM |
Hand held single wheel | 0-4KM/H | / | 30% | 23L | 60HZ | 4KW | 1450*770*1250MM |
Hand held dual wheels | 0-4KM/H | / | 25% | 25L | 70HZ | 6KW | 2350*755*1710MM |
Electric roller | 0-6KM/H | / | 30% | 85L | 70HZ | 15KW | 2300*1130*2400MM |
Product Show
Product Feature
1. Strong compaction ability: The roller uses its vibration wheel or smooth wheel to perform high-frequency vibration or static compaction on the road surface material,which can effectively reduce the gaps and cracks between materials, improve the compactness and stability of the road surface.This efficient compaction capability can greatly shorten the construction period and improve construction efficiency.
2. Fast construction speed: Compared with traditional manual or simple mechanical compaction methods, road rollers can complete a larger area of compaction work in a shorter time, thereby accelerating the construction progress.
3. Diverse construction environments: Road rollers are not only suitable for flat road construction, but also for construction in complex terrains such as mountainous and hilly areas, with strong environmental adaptability.
4. High energy utilization rate: Modern road rollers focus on efficient energy utilization in their design, reducing energy consumption and operating costs by optimizing engine performance and transmission systems.
2. Fast construction speed: Compared with traditional manual or simple mechanical compaction methods, road rollers can complete a larger area of compaction work in a shorter time, thereby accelerating the construction progress.
3. Diverse construction environments: Road rollers are not only suitable for flat road construction, but also for construction in complex terrains such as mountainous and hilly areas, with strong environmental adaptability.
4. High energy utilization rate: Modern road rollers focus on efficient energy utilization in their design, reducing energy consumption and operating costs by optimizing engine performance and transmission systems.
1. Dashboard
Accurate display and convenient operation
2. Adjustable handle
The handle can be adjusted according to the user's height and habits
Accurate display and convenient operation
2. Adjustable handle
The handle can be adjusted according to the user's height and habits
3. Bearings and belts
Internationally renowned bearings and high-quality belts ensure the working performance of the machine.
4. Engine
Superior performance, strong power, and high efficiency.
Internationally renowned bearings and high-quality belts ensure the working performance of the machine.
4. Engine
Superior performance, strong power, and high efficiency.
Product Application
Widely used in road construction, airport runways, dam engineering, municipal engineering,industrial sites and other fields.
Company Information
Packing&Delivery
Jining Xinta Heavy Industry Machinery Co., Ltd. was established in 2016 and is located in the historic city of Jining, which has Confucian culture and thought. The company covers an area of 200 acres, has fixed assets of billions of yuan, more than 200 employees, and more than 20 engineering and technical personnel. The company has a long history in the research, processing, production, and sales of agricultural machinery. Its products comply with CE certification/EPA
certification/ISO quality certification and are exported to Europe, America, Southeast Asia, Central Asia, and other countries and regions to establish stable cooperative relationships. We have independent research and development capabilities, complete processing technology, spacious workshop scale, precise processing equipment, and strict management. We are a large enterprise integrating design, research and development, production, and sales, mainly producing remote-controlled lawn mowers, excavators,rollers, etc.
certification/ISO quality certification and are exported to Europe, America, Southeast Asia, Central Asia, and other countries and regions to establish stable cooperative relationships. We have independent research and development capabilities, complete processing technology, spacious workshop scale, precise processing equipment, and strict management. We are a large enterprise integrating design, research and development, production, and sales, mainly producing remote-controlled lawn mowers, excavators,rollers, etc.
FQA
Q1: Are you trading company or manufacturer?
We are factory. We can design and manufacture products with our patent, Welcome to visit our factory.
Q2: How to guarantee customers get the goods smoothly after they pay?
We joined the trade assurance, you can place the order by trade assurance, and the deposit will given to Alibaba. If we don't delivery products on time, the deposit will return to you.
Q3: How do you ensure the quality of your products?
Generally, our machines are the most durable type in the industry. With our experienced quality control team, we are trying to offer most of our customers the product with best quality.
Q4:How would the goods be shipped?
We can ship it by sea or by land
Q5:What method of payment do you accept?
A:We accept ACP,Western Union,T/T,pay pal,money gram,Secure Payment.
We are factory. We can design and manufacture products with our patent, Welcome to visit our factory.
Q2: How to guarantee customers get the goods smoothly after they pay?
We joined the trade assurance, you can place the order by trade assurance, and the deposit will given to Alibaba. If we don't delivery products on time, the deposit will return to you.
Q3: How do you ensure the quality of your products?
Generally, our machines are the most durable type in the industry. With our experienced quality control team, we are trying to offer most of our customers the product with best quality.
Q4:How would the goods be shipped?
We can ship it by sea or by land
Q5:What method of payment do you accept?
A:We accept ACP,Western Union,T/T,pay pal,money gram,Secure Payment.
