High quality 6000w power inverter 6kw 24vdc 48vdc to 220vac high efficiency in stock
- Category: >>>
- Supplier: Foshan Top One Power Technology Co. Ltd.
Share on (1601218693861):
Product Overview
Description
Product Description
Specification
Model | FT-152 | FT-202 | FT-302 | FT-402 | FT-502 | FT-602 | ||||||
Rated power | 1.5KW | 2KW | 3KW | 4KW | 5KW | 6KW | ||||||
Surge power | 4.5KW | 6KW | 9KW | 12KW | 15KW | 18KW | ||||||
AC Input & Output | ||||||||||||
Voltage | 220VAC | |||||||||||
Selectable Voltage Range | 165-275VAC (220VAC) | |||||||||||
Frequency Range | 50Hz/60Hz automatic recognition | |||||||||||
AC Voltage Regulation | (DC Batt.mode)220vac±3% | |||||||||||
Transfer Time | ≤4ms | |||||||||||
Wave Form | Pure Sine Wave | |||||||||||
Transformer type | Toroidal | |||||||||||
Transfer efficiency | ≥85% | |||||||||||
Battery | ||||||||||||
Battery Voltage | 12V/24V/48V | 24V/48V | ||||||||||
Type | Gel/SLA/AGM/Water/Lithium(lifepo4) Battery | |||||||||||
DC Charge Voltage | 12~16VDC(12V)/20~32VDC(24V)/40~64VDC(48V) | |||||||||||
Overcharge Protection | Battery voltage ≧16VDC (12V) ≧32VDC (24V) ≧64VDC (48V), stop charging after 60s alarm | |||||||||||
AC Charger | ||||||||||||
Maximum AC Charge Current | 35A (adjustable) | |||||||||||
Working mode | ||||||||||||
01 mode | AC mains priority mode | |||||||||||
02 mode | ECO mode | |||||||||||
03 mode | DC battery priority mode | |||||||||||
04 mode | Generator mode | |||||||||||
05 mode | Unattended mode | |||||||||||
Communication Port | ||||||||||||
Type | RS485, available for wifi box & external control screen | |||||||||||
Packing Details | ||||||||||||
Dimension, D*W*H(MM) | 600*380*270 | 780*380*280 | ||||||||||
G.W.(KGS) | 17 | 19 | 21 | 31 | 33 | 35 | ||||||
Environment | ||||||||||||
Humidity | 0~95%（NO CONDENSATION) | |||||||||||
Operating Temperature | 0~60℃ | |||||||||||
Storage Temperature | 0~60℃ | |||||||||||
*Product Specifications Are Subject To Change Without Further Notice | ||||||||||||
Packing & Delivery
To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.
Our Advantages
Company Profile
FAQ
Q1: Does your company also provide other solar products except Pure Sine Wave Inverter?
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, Lifepo4 battery, water pump inverter, high frequency inverter and other accessories related to the solar power system.
Q2: How to choose a right inverter?
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?
A3: 5 days for sample; 7-15 days for bulk order.
Q4: What is the warranty of inverter?
A4: 1 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
A1: Yes, we also provide other solar products, like MPPT Solar Controller, off grid solar inverter, Lifepo4 battery, water pump inverter, high frequency inverter and other accessories related to the solar power system.
Q2: How to choose a right inverter?
A2: Tell us your demand, then our sales will recommend a suitable inverter to you.
Q3: How about the delivery time?
A3: 5 days for sample; 7-15 days for bulk order.
Q4: What is the warranty of inverter?
A4: 1 year warranty.
Q5: How to solve the technical problem?
A5: 24 hours after-service consultancy just for you and to make your problem to solve easily.
