100x100x1.1mm 1.3mm 2.2mm 7 10ohm FTO Resistance Glass for Solar Panel
- Category: >>>
- Supplier: Dongguan Saida Glass Co. Ltd.Dongguan Ltd.
Share on (1601219044477):
Product Overview
Description
Conductive Glass Sheet for Lab.
Electronic Level/High Precision/Super Flatness
Available with Mulitiple Process
Round Shape
Square Shape
Polished Edge
Parameter Information
Product Name | ITO/FTO Conductive Glass | ||||||||||||||||
Size | Customzied as request | ||||||||||||||||
Thickness | 0.2-3mm | ||||||||||||||||
Conductive Value | 3ohm, 5ohm, 7ohm, 8ohm, 10ohm, 15ohm, 20ohm, 30ohm, 50ohm, 70ohm, 100ohm, 150ohm, 300ohm and etc. | ||||||||||||||||
Thickness Tolerance | +/-0.05mm | ||||||||||||||||
Flatness | </=0.10% | ||||||||||||||||
Product Introduction
ITO Conductive Glass
1. ITO conductive glass is manufactured by depositing silicon dioxide (SiO2) and indium tin oxide (commonly referred to as ITO) thin films on the basis of soda-lime or borosilicate glass by using a magnetron measurement method.
2. ITO is a metal compound with good transparent and conductive properties. It has the characteristics of forbidden bandwidth, high light transmittance and low resistivity in the visible spectrum region. It is widely used in affirmative display devices, solar cells, and special functional window coatings. Laboratory equipment and other optoelectronic devices.
2. ITO is a metal compound with good transparent and conductive properties. It has the characteristics of forbidden bandwidth, high light transmittance and low resistivity in the visible spectrum region. It is widely used in affirmative display devices, solar cells, and special functional window coatings. Laboratory equipment and other optoelectronic devices.
FTO Conductive Glass
1. FTO conductive glass is fluorine-doped SnO2 transparent conductive glass (SnO2: F), referred to as FTO.
2. SnO2 is a wide band-gap oxide semiconductor that is transparent to visible light, with a band gap of 3.7-4.0eV, and has a regular tetrahedral gold red structure. After being doped with fluorine, the SnO2 film has the advantages of good light transmittance to visible light, large ultraviolet absorption coefficient, low resistivity, stable chemical properties, and strong resistance to acid and alkali at room temperature.
2. SnO2 is a wide band-gap oxide semiconductor that is transparent to visible light, with a band gap of 3.7-4.0eV, and has a regular tetrahedral gold red structure. After being doped with fluorine, the SnO2 film has the advantages of good light transmittance to visible light, large ultraviolet absorption coefficient, low resistivity, stable chemical properties, and strong resistance to acid and alkali at room temperature.
Our Factory
Saida Glass was founded in 2011, which is located in Dongguan, near to Shenzhen and Guangzhou port. With over Ten years'
experience in glass deep processing, specialized in customized glass, we work with many large-scale global enterprises such as
Lenovo, HP, TCL, Sony, Glanz, Gree, CAT and other companies.
We have 3,500 square meters production base, 30 R&D staff with twelve years' experience, 120 QA staff with seven years'
experience. Our products passed ASTMC1048 (the US), EN12150 (EU), AS/NZ2208 (AU) and CAN/CGSB-12.1-M90 (CA). Thus, 98% of customer
are satisfined with our one-stop services.
We have been engaged in export for seven years. Our major export markets are North America, Europe, Oceania and Asia. We are
offering glass deep processing services to SEB, FLEX, Kohler, Fitbit and Tefal.
experience in glass deep processing, specialized in customized glass, we work with many large-scale global enterprises such as
Lenovo, HP, TCL, Sony, Glanz, Gree, CAT and other companies.
We have 3,500 square meters production base, 30 R&D staff with twelve years' experience, 120 QA staff with seven years'
experience. Our products passed ASTMC1048 (the US), EN12150 (EU), AS/NZ2208 (AU) and CAN/CGSB-12.1-M90 (CA). Thus, 98% of customer
are satisfined with our one-stop services.
We have been engaged in export for seven years. Our major export markets are North America, Europe, Oceania and Asia. We are
offering glass deep processing services to SEB, FLEX, Kohler, Fitbit and Tefal.
Customer Visiting & Feedback
Packaging
Apply protecive film on each side
500pcs or more per vacuum package
1000pcs or more per box
